Номер на схеме	Каталожный номер	Название	Количество
?	PB6233	SWITCH, BATTERY DISCONNECT	2
?	TR1306	CAPSCREW - 1/4" - 20NC X 1"	8
?	DC3584	LOCKWASHER - 1/4"	15
?	SP8417	FLAT WASHER - 1/4"	8
?	TD1549	NUT - 1/4" - 20NC	12
?	TR5445	LOCKWASHER - 1/2"	4
?	EC0444	BRACKET	1
?	EC7203	STRIP, RUBBER	2
?	PB7104	BREAKER, CIRCUIT - 20 AMP	4
?	TD1548	CAPSCREW - 1/4" - 20NC X 5/8"	2
?	EC7201	WIRE	4
?	WB0800	LABEL, BREAKER	1
?	TG5720	CAPSCREW - 3/8" - 16NC X 1"	15
?	TC1231	LOCKWASHER - 3/8"	15
?	TC1233	NUT - 3/8" - 16NC	12
?	TZ6939	PLATE, MOUNTING	1
?	TZ6940	GASKET	1
?	EC8230	CABLE, BATTERY	1
?	TZ0527	WIRE	1
?	PB7924	MONITOR, BATTERY	1
?	VC9144	MACHINE SCREW - #8 - 32NC X 1/2"	4
?	VM9910	LOCKWASHER - #8	4
?	TZ0526	WIRE	1
?	PB6977	EQUALIZER, BATTERY	1
?	TG1929	MACHINE SCREW - #10 - 24NC X 1/2"	4
?	DC3101	LOCKWASHER - #10	8
?	VC5344	FLAT WASHER - #10	4
?	ED2228	BOX, EQUALIZER	1
?	TZ0535	BAR, BUS	1
?	VM1464	MACHINE SCREW - #10 - 24NC X 5/8"	4
?	DF0017	NUT - #10 - 24NC	6
?	TZ0538	SPACER	3
?	PB0429	INSULATOR, STAND-OFF	3
?	EC7744	CABLE, BATTERY	1
?	DL1371	GROMMET	5
?	TZ0546	CABLE	1
?	TD1809	CAPSCREW - 1/4" - 20NC X 3/4"	5
?	TZ6937	BAR, BUS	1
?	TA7409	INSULATOR, STAND-OFF	1
?	TZ0528	WIRE	1
?	EC8232	CABLE, BATTERY	1
?	EC8231	CABLE, BATTERY	1
?	TZ6936	BAR, BUS	1
?	EC3117	WIRE	1
?		THIS PAGE COVERS DDEC II UNIT ONLY.
?		(SEE FOLLOWING PAGE FOR DDEC III CONVERSION)
