| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB0266 | ADAPTER - 45 DEG | 1 | ||||
| ? | TF5069 | ADAPTER - 90 DEG | 2 | ||||
| ? | E2579 | NIPPLE, CLOSE | 1 | ||||
| ? | SD5214 | FITTING, PIPE | 1 | ||||
| ? | TC8486 | ADAPTER - 90 DEG | 1 | ||||
| ? | HA0904 | HOSE - FUEL RETURN TO JUNCTION BLOCK | 1 | ||||
| ? | HA0946 | HOSE - FUEL RETURN TO PRIMARY FILTERS | 1 | ||||
| ? | DC3418 | NIPPLE, CLOSE | 1 | ||||
| ? | PB2306 | VALVE, SHUT-OFF | 1 | ||||
| ? | TD8121 | ADAPTER, STRAIGHT | 1 | ||||
| ? | C1614 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 4 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 9 | ||||
| ? | FILTER, FUEL - PRIMARY | 2 | |||||
| ? | VE6714 | • ELEMENT (SPIN-ON) | 2 | ||||
| ? | HA0270 | HOSE - SECONDARY FILTER TO FUEL MANIFOLD | 1 | ||||
| ? | C1613 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 4 | ||||
| ? | WB0273 | ELBOW - 90 DEG | 1 | ||||
| ? | FILTER - SECONDARY | 2 | |||||
| ? | VE0047 | • ELEMENT (SPIN-ON) | 2 | ||||
| ? | HA0524 | HOSE - FUEL PUMP TO SECONDARY FILTER | 1 | ||||
| ? | HA0443 | HOSE - PRIMARY FILTERS TO FUEL PUMP | 1 | ||||
| ? | C1523 | NUT - 1/2" - 13NC | 1 | ||||
| ? | VN9913 | CLAMP | 1 | ||||
| ? | WA2256 | ELD STUD - 1/2" - 13NC X 1 1/4" | 1 | ||||
| ? | HD8019 | BUSHING, PIPE | 1 | ||||
| ? | WB0363 | ADAPTER, STRAIGHT | 1 | ||||
| ? | C5770 | PLUG, PIPE | 1 | ||||
| ? | C5771 | PLUG, PIPE | 2 | ||||
| ? | TG1655 | ELBOW - 90 DEG | 1 | ||||
| ? | H6881 | PLUG, PIPE | 4 | ||||
| ? | E2579 | NIPPLE, CLOSE | 1 | ||||
| ? | C5771 | PLUG, PIPE | 1 | ||||
| ? | VF7848 | ADAPTER - 45 DEG | 1 | ||||
| ? | E2577 | TEE | 1 | ||||
| ? | WB0297 | ELBOW - 45 DEG | 1 |
