Номер на схеме	Каталожный номер	Название	Количество
?	VE8070	COLLAR	2
?	VE8071	PLUNGER	2
?		SEAL (1)	2
?		SPRING, PLUNGER (1)	2
?		SPRING, REGULATOR (1)	2
?		SPRING, REGULATOR (1)	2
?	VE8532	SEAT, SPRING	2
?		SPOOL (3)	2
?		RING, BACKUP (2)	2
?		SEAL (2)	2
?		RING, BACKUP (2)	2
?		SEAL (2)	2
?		SEAL (2)	2
?		SLEEVE (3)	2
?		SPRING, SPOOL (1)	2
?		PLUNGER, REACTION (3)	1
?		PLUNGER, REACTION (3)	1
?		SEAL, WIPER (2)	2
?		RING, BACKUP (2)	2
?		SEAL (2)	2
?		BODY (4)	1
?		SEAL (2)	1
?		SEAL (2)	1
?	VE8533	SCREW	1
?		SEAL (2)	1
?		PLUG (5)	1
?		SLEEVE, RETAINER	1
?	C1546	FLAT WASHER - 1/4"	4
?	VE8534	SCREW	4
?	VE8528	NOTE: (1) INCLUDED IN VE8528 SPRING KIT.
?	VE8529	(2) INCLUDED IN VE8529 SEAL KIT.
?	VE8531	(3) INCLUDED IN VE8531 SPOOL/SLEEVE KIT.
?		(4) NOT SERVICED SEPARATELY.
