| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE6119 | PANEL, RESISTOR | 1 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 14 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 14 | ||||
| ? | MM0177 | NUT - M8 | 14 | ||||
| ? | PB5234 | PANEL, STATIC EXCITER | 1 | ||||
| ? | VS0035 | DOME LIGHT | 1 | ||||
| ? | VZ1912 | • BULB | 2 | ||||
| ? | TM9090 | • INSULATOR | 2 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 3 | ||||
| ? | TG1929 | MACHINE SCREW - #10 - 24NC X 1/2" | 3 | ||||
| ? | EC2716 | STRIP, SEAL | 4 | ||||
| ? | EC2717 | STRIP, SEAL | 4 | ||||
| ? | PB8837 | PANEL, STATIC EXCITER | 1 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 4 | ||||
| ? | TR6008 | FLAT WASHER - 1/2" | 4 | ||||
| ? | PB3348 | INSULATOR | 4 | ||||
| ? | PB5692 | PANEL - ON L.H. WALL | 1 | ||||
| ? | PB7875 | RESISTOR | 1 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 8 | ||||
| ? | MM0378 | LOCKWASHER - 4MM (EXTERNAL TOOTH) | 8 | ||||
| ? | MM0372 | NUT - M4 | 8 | ||||
| ? | PB5230 | RESISTOR | 1 | ||||
| ? | EC2026 | HOUSING - CURRENT TRANSFORMER RESISTOR | 1 | ||||
| ? | TK7659 | RESISTOR | 1 | ||||
| ? | VJ9204 | TRANSFORMER, RIPPLE | 1 | ||||
| ? | VE6113 | PANEL, FDP | 1 | ||||
| ? | PB4262 | TRANSFORMER, CURRENT | 1 | ||||
| ? | MM0027 | CAPSCREW - M6 X 1.00 X 25 | 2 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 2 | ||||
| ? | VE5107 | CAPACITOR - ON R.H. WALL | 2 | ||||
| ? | PB4252 | PANEL, ISO AMP - ON R.H. WALL | 6 | ||||
| ? | PB3347 | SHUNT - ON R.H. WALL | 2 | ||||
| ? | PB4267 | PANEL - ON L.H. WALL & FLOOR | 2 | ||||
| ? | EC7460 | NAME PLATE - DL4 | 1 | ||||
| ? | ED0359 | NAME PLATE - 74AA | 3 | ||||
| ? | TZ7543 | NAME PLATE - R1 | 1 | ||||
| ? | ED0358 | NAME PLATE - 71J | 2 | ||||
| ? | ED0372 | NAME PLATE - 74E | 1 | ||||
| ? | ED0360 | NAME PLATE - 75X | 2 | ||||
| ? | ED0370 | NAME PLATE - 7J13 | 1 | ||||
| ? | ED0369 | NAME PLATE - 71K | 1 | ||||
| ? | TZ7514 | NAME PLATE - MFSE | 1 | ||||
| ? | TZ7513 | NAME PLATE - AFSE | 1 | ||||
| ? | ED0363 | NAME PLATE - 7J9 | 2 | ||||
| ? | ED0362 | NAME PLATE - 74D | 1 | ||||
| ? | ED0361 | NAME PLATE - 71G | 1 | ||||
| ? | TZ7517 | NAME PLATE - 7DP | 1 | ||||
| ? | TZ7546 | NAME PLATE - S6 | 1 | ||||
| ? | TZ7547 | NAME PLATE - S7 | 1 | ||||
| ? | TZ7519 | NAME PLATE - MFDR | 1 | ||||
| ? | TZ7518 | NAME PLATE - GFDR | 1 | ||||
| ? | ED0366 | NAME PLATE - 7J4 | 1 | ||||
| ? | ED0364 | NAME PLATE - 74 | 1 | ||||
| ? | ED0375 | NAME PLATE - 74B | 1 | ||||
| ? | EC7463 | NAME PLATE - FDT | 1 | ||||
| ? | ED0365 | NAME PLATE - 74A | 1 | ||||
| ? | ED0384 | NAME PLATE - 710 | 1 | ||||
| ? | EC7257 | NAME PLATE - CTR | 1 | ||||
| ? | ED0368 | NAME PLATE - 7J14 | 1 | ||||
| ? | ED0374 | NAME PLATE - 74F | 1 | ||||
| ? | ED0373 | NAME PLATE - 74C | 1 | ||||
| ? | TZ7516 | NAME PLATE - CT | 1 |
