| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 196-03-00062 | OIL COOLER ASS'Y | 1 | SN: 31416- |
|||
| ? | □196-03-00061 | OIL COOLER ASS'Y | 1 | SN: 31271-31415 |
|||
| ? | □196-03-00060 | OIL COOLER ASS'Y | 1 | SN: 15686-31270 |
|||
| ? | 196-03-13110 | • CASE | 1 | SN: 15686- |
|||
| ? | 195-03-19130 | • COOLER | 4 | SN: 15686- |
|||
| ? | 196-03-13140 | • COOLER | 2 | SN: 15686- |
|||
| ? | 07000-62014 | • O-RING | 24 | SN: 15686- |
|||
| ? | 07000-63032 | • O-RING | 12 | SN: 15686- |
|||
| ? | 196-03-13151 | • GASKET | 2 | SN: 31271- |
|||
| ? | □196-03-13150 | • GASKET | 2 | SN: 15686-31270 |
|||
| ? | 196-03-13120 | • COVER | 1 | SN: 15686- |
|||
| ? | 196-03-13130 | • COVER | 1 | SN: 15686- |
|||
| ? | 195-03-19190 | • PLUG | 10 | SN: 15686-21738 |
|||
| ? | 01580-00806 | • NUT | 24 | SN: 15686- |
|||
| ? | 01602-00825 | • WASHER,SPRING | 24 | SN: 15686- |
|||
| ? | 01010-81030 | • BOLT | 56 | SN: 15686- |
|||
| ? | 01602-01030 | • WASHER,SPRING | 56 | SN: 15686- |
|||
| ? | 07000-03038 | O-RING | 4 | SN: 15686- |
|||
| ? | 195-03-19110 | FLANGE | 3 | SN: 15686- |
|||
| ? | 01010-81240 | BOLT | 12 | SN: 15686- |
|||
| ? | 01643-31232 | WASHER | 12 | SN: 21739- |
|||
| ? | □01602-01236 | WASHER,SPRING | 12 | SN: 15686-21738 |
|||
| ? | 195-03-13241 | VALVE | 1 | SN: 31416- |
|||
| ? | □07730-30004 | VALVE | 1 | SN: 15686-31415 |
|||
| ? | 195-03-13180 | HOSE | 1 | SN: 15686- |
|||
| ? | 07285-00180 | CLIP | 1 | SN: 31416- |
|||
| ? | □04059-01016 | WIRE,LOCK | 1 | SN: 15686-31415 |
|||
| ? | 01010-81645 | BOLT | 5 | SN: 15686- |
|||
| ? | 01602-01648 | WASHER,SPRING | 5 | SN: 15686-21738 |
|||
| ? | 01643-31645 | WASHER | 5 | SN: 15686- |
|||
| ? | 195-03-12561 | GASKET | 1 | SN: 31271- |
|||
| ? | □195-03-12560 | GASKET | 1 | SN: 15686-31270 |
|||
| ? | 175-03-34142 | TUBE | 1 | SN: 15686- |
|||
| ? | 01010-81040 | BOLT | 2 | SN: 15686- |
|||
| ? | 01580-01008 | NUT | 2 | SN: 15686- |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 15686- |
|||
| ? | 07332-02400 | COUPLING | 1 | SN: 15686- |
|||
| ? | 07332-52400 | • GASKET | 2 | SN: 15686- |
|||
| ? | 07332-62400 | • CLAMP | 2 | SN: 15686- |
|||
| ? | 175-03-00012 | TUBE ASS'Y | 1 | SN: 15686- |
|||
| ? | ☆ | • TUBE | 1 | SN: 15686- |
|||
| ? | 07040-11612 | • PLUG | 1 | SN: 15686- |
|||
| ? | 07005-01612 | • GASKET | 1 | SN: 15686- |
|||
| ? | 01010-81040 | BOLT | 4 | SN: 15686- |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 15686- |
|||
| ? | 195-03-12341 | GASKET | 1 | SN: 31271- |
|||
| ? | □195-03-12340 | GASKET | 1 | SN: 15686-31270 |
|||
| ? | 195-03-12820 | GASKET | 1 | SN: 31271- |
|||
| ? | □195-03-12321 | GASKET | 1 | SN: 15686-31270 |
|||
| ? | 01010-81035 | BOLT | 3 | SN: 15686- |
|||
| ? | 01602-01030 | WASHER,SPRING | 3 | SN: 15686- |
|||
| ? | 175-03-00132 | TUBE ASS'Y | 1 | SN: 15686- |
|||
| ? | ☆ | • TUBE | 1 | SN: 15686- |
|||
| ? | 07040-11612 | • PLUG | 1 | SN: 15686- |
|||
| ? | 07005-01612 | • GASKET | 1 | SN: 15686- |
|||
| ? | 07332-02400 | COUPLING | 1 | SN: 15686- |
|||
| ? | ☆ | • GASKET | 2 | SN: 15686- |
|||
| ? | ☆ | • CLAMP | 2 | SN: 15686- |
|||
| ? | 175-03-34122 | TUBE | 1 | SN: 15686- |
|||
| ? | 01010-81040 | BOLT | 4 | SN: 15686- |
|||
| ? | 01602-01030 | WASHER,SPRING | 4 | SN: 15686- |
|||
| ? | 195-03-12341 | GASKET | 1 | SN: 31271- |
|||
| ? | □195-03-12340 | GASKET | 1 | SN: 15686-31270 |
|||
| ? | 176-03-43150 | FLANGE | 1 | SN: 15686- |
|||
| ? | 07000-03042 | O-RING | 1 | SN: 15686- |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 15686- |
|||
| ? | 01602-21030 | WASHER | 2 | SN: 15686- |
