| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (17A-27-00031) | FINAL DRIVE ASS'Y,L.H. | 1 | SN: 70237- |
|||
| ? | (17A-27-00030) | FINAL DRIVE ASS'Y,L.H. | 1 | SN: 70001-70236 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2380-01A0 AND F2380-02A0. | ||||||
| ? | 17A-27-11152 | • HUB | 1 | SN: 70237- |
|||
| ? | 17A-27-11151 | • HUB | 1 | SN: 70001-70236 |
|||
| ? | 17A-27-11630 | • TOOTH | 9 | SN: 70001- |
|||
| ? | 178-27-11150 | • BOLT | 27 | SN: 70001- |
|||
| ? | 01803-02430 | • NUT | 27 | SN: 70001- |
|||
| ? | 17A-27-11331 | • BEARING | 2 | SN: 70001- |
|||
| ? | 17A-27-11450 | • COLLAR | 1 | SN: 70001- |
|||
| ? | 423-33-00020 | • FLOATING SEAL ASS'Y | 1 | SN: 70001- |
|||
| ? | ☆ | • • RING | 2 | SN: 70001- |
|||
| ? | ☆ | • • O-RING | 2 | SN: 70001- |
|||
| ? | 17A-27-11271 | • HUB | 1 | SN: 70001- |
|||
| ? | 17A-27-11261 | • GEAR | 1 | SN: 70001- |
|||
| ? | 17A-27-11461 | • LOCK | 6 | SN: 70001- |
|||
| ? | 01010-81025 | • BOLT | 12 | SN: 70001- |
|||
| ? | 01643-31032 | • WASHER | 12 | SN: 70001- |
|||
| ? | 17A-27-00020 | • SHIM ASS'Y | 1 | SN: 70001- |
|||
| ? | ☆ | • • SHIM¤ 1.0MM | 2 | SN: 70001- |
|||
| ? | ☆ | • • SHIM¤ 0.5MM | 2 | SN: 70001- |
|||
| ? | ☆ | • • SHIM¤ 0.2MM | 3 | SN: 70001- |
|||
| ? | ☆ | • • SHIM¤ 0.15MM | 3 | SN: 70001- |
|||
| ? | 17A-27-11441 | • HOLDER | 1 | SN: 70001- |
|||
| ? | 01010-62050 | • BOLT | 10 | SN: 70001- |
|||
| ? | 17A-27-11161 | • CARRIER | 1 | SN: 70001- |
|||
| ? | 17A-27-11321 | • BEARING | 6 | SN: 70001- |
|||
| ? | 17A-27-11251 | • GEAR | 3 | SN: 70001- |
|||
| ? | 17A-27-11511 | • SHAFT | 3 | SN: 70001- |
|||
| ? | 17A-27-11521 | • LOCK | 3 | SN: 70001- |
|||
| ? | 01010-81235 | • BOLT | 6 | SN: 70001- |
|||
| ? | 01643-31232 | • WASHER | 6 | SN: 70001- |
|||
| ? | 07044-13620 | • PLUG | 3 | SN: 70001- |
|||
| ? | 07002-13634 | • O-RING | 3 | SN: 70001- |
|||
| ? | 07049-02025 | • PLUG | 3 | SN: 70001- |
|||
| ? | 01010-62055 | • BOLT | 36 | SN: 70001- |
|||
| ? | 01643-32060 | • WASHER | 36 | SN: 70001- |
|||
| ? | 195-09-18340 | • O-RING | 1 | SN: 70001- |
|||
| ? | 17A-27-11241 | • PINION | 1 | SN: 70001- |
|||
| ? | 195-22-12580 | • BUTTON | 2 | SN: 70001- |
|||
| ? | 17A-27-11431 | • COVER | 1 | SN: 70001- |
|||
| ? | 04260-01905 | • BALL | 1 | SN: 70001- |
|||
| ? | 07000-15145 | • O-RING | 1 | SN: 70001- |
|||
| ? | 01010-81230 | • BOLT | 3 | SN: 70001- |
|||
| ? | 01643-31232 | • WASHER | 3 | SN: 70001- |
|||
| ? | 07049-01215 | • PLUG | 2 | SN: 70001- |
|||
| ? | 17A-27-11471 | • COVER,L.H. | 1 | SN: 70001- |
|||
| ? | 04260-01905 | • BALL | 1 | SN: 70001- |
|||
| ? | 07000-12075 | • O-RING | 1 | SN: 70001- |
|||
| ? | 01010-81230 | • BOLT | 3 | SN: 70001- |
|||
| ? | 01643-31232 | • WASHER | 3 | SN: 70001- |
|||
| ? | 01011-62715 | BOLT | 12 | SN: 70001- |
|||
| ? | 01010-62775 | BOLT | 8 | SN: 70001- |
|||
| ? | 01643-32780 | WASHER | 20 | SN: 70001- |
