| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO. | ||||||
| ? | (17A-15-31000) | TRANSMISSION ASS'Y | 1 | SN: 76001- |
|||
| ? | (17A-15-21012) | TRANSMISSION ASS'Y | 1 | SN: 75001-75999 |
|||
| ? | (17A-15-21011) | TRANSMISSION ASS'Y | 1 | SN: (1112)-074999 |
|||
| ? | (17A-15-21010) | TRANSMISSION ASS'Y | 1 | SN: 70001-(1111) |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-61A0. | ||||||
| ? | 17M-15-42320 | • CARRIER | 1 | SN: (1435)- |
|||
| ? | 17A-15-22321 | • CARRIER | 1 | SN: 70001-(1434) |
|||
| ? | 17M-15-42420 | • GEAR | 4 | SN: (1452)- |
|||
| ? | 17A-15-22421 | • GEAR | 4 | SN: 70001-(1451) |
|||
| ? | 17M-15-39440 | • BEARING | 4 | SN: (1452)- |
|||
| ? | 175-15-69420 | • BEARING | 4 | SN: 70001-(1451) |
|||
| ? | 561-15-32590 | • WASHER | 8 | SN: 70001- |
|||
| ? | 17M-15-42540 | • SHAFT | 4 | SN: (1452)- |
|||
| ? | 17A-15-22540 | • SHAFT | 4 | SN: 70001-(1451) |
|||
| ? | 04260-00635 | • BALL | 4 | SN: 70001- |
|||
| ? | 17A-15-22620 | • GEAR | 1 | SN: 70001- |
|||
| ? | 17A-15-29520 | • RING | 1 | SN: 70001- |
|||
| ? | 17A-15-22160 | • SPACER | 1 | SN: 70001- |
|||
| ? | 04070-00150 | • RING | 1 | SN: 70001- |
|||
| ? | 17M-15-42310 | • CARRIER | 1 | SN: (1452)- |
|||
| ? | 17A-15-22311 | • CARRIER | 1 | SN: 70001-(1451) |
|||
| ? | 17M-15-42410 | • GEAR | 4 | SN: (1452)- |
|||
| ? | 17A-15-22411 | • GEAR | 4 | SN: 70001-(1451) |
|||
| ? | 17M-15-39440 | • BEARING | 4 | SN: (1452)- |
|||
| ? | 175-15-69420 | • BEARING | 4 | SN: 70001-(1451) |
|||
| ? | 561-15-32590 | • WASHER | 8 | SN: 70001- |
|||
| ? | 17M-15-42540 | • SHAFT | 4 | SN: (1452)- |
|||
| ? | 17A-15-22540 | • SHAFT | 4 | SN: 70001-(1451) |
|||
| ? | 04260-00635 | • BALL | 4 | SN: 70001- |
|||
| ? | 17A-15-22610 | • GEAR | 1 | SN: 70001- |
|||
| ? | 17A-15-29510 | • RING | 1 | SN: 70001- |
|||
| ? | 17A-15-22151 | • SPACER | 1 | SN: 70001- |
|||
| ? | 06000-06212 | • BEARING | 1 | SN: 70001- |
|||
| ? | 04065-01104 | • RING | 1 | SN: 70001- |
|||
| ? | 06030-06928 | • BEARING | 1 | SN: 70001- |
|||
| ? | 04070-00140 | • RING | 1 | SN: 70001- |
|||
| ? | 04064-06020 | • RING | 3 | SN: 70001- |
|||
| ? | 17A-15-22140 | • SPACER | 1 | SN: 70001- |
|||
| ? | 17A-15-22210 | • GEAR | 1 | SN: 70001- |
|||
| ? | 17M-15-42220 | • GEAR | 1 | SN: (1452)- |
|||
| ? | 17A-15-22220 | • GEAR | 1 | SN: 70001-(1451) |
|||
| ? | 04064-07525 | • RING | 1 | SN: 70001- |
|||
| ? | 04065-01154 | • RING | 1 | SN: 70001- |
|||
| ? | 17A-15-29321 | • BEARING | 1 | SN: 75242- |
|||
| ? | 17A-15-29320 | • BEARING | 1 | SN: (101487)-00075241 |
|||
| ? | 06030-06015 | • BEARING | 1 | SN: (1452)-(101486) |
|||
| ? | 06000-06015 | • BEARING | 1 | SN: 70001-(1451) |
|||
| ? | 17A-15-22190 | • SPACER | 1 | SN: 70001- |
|||
| ? | 17M-15-42250 | • GEAR | 1 | SN: (1452)- |
|||
| ? | 17A-15-22250 | • GEAR | 1 | SN: 70001-(1451) |
|||
| ? | 17A-15-22181 | • SPACER | 1 | SN: 70001- |
|||
| ? | 06000-06019 | • BEARING | 1 | SN: 70001- |
|||
| ? | 17M-15-42240 | • GEAR | 1 | SN: (1452)- |
|||
| ? | 17A-15-22241 | • GEAR | 1 | SN: 70001-(1451) |
|||
| ? | 17A-15-22171 | • SPACER | 1 | SN: 70001- |
|||
| ? | 04064-06525 | • RING | 1 | SN: 70001- |
