| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 155-03-00013 | RADIATOR ASS'Y,G-TYPE | 1 | SN: .- |
|||
| ? | □155-03-00012 | RADIATOR ASS'Y,G-TYPE | 1 | SN: 1279-. |
|||
| ? | 155-03-00041 | RADIATOR ASS'Y,D-TYPE (OP) | 1 | SN: .- |
|||
| ? | □155-03-00040 | RADIATOR ASS'Y,D-TYPE (OP) | 1 | SN: 1279-. |
|||
| ? | 155-03-11114 | • TANK,UPPER | 1 | SN: .- |
|||
| ? | □155-03-11113 | • TANK,UPPER | 1 | SN: 1279-. |
|||
| ? | 154-03-11681 | • VALVE,PRESSURE | 1 | SN: 1003- |
|||
| ? | 01010-31025 | • BOLT | 1 | SN: 1003- |
|||
| ? | 01602-01030 | • WASHER,SPRING | 2 | SN: 1003- |
|||
| ? | 07000-03045 | • O-RING | 1 | SN: 1003- |
|||
| ? | 07056-00048 | • STRAINER | 1 | SN: 1279- |
|||
| ? | 07057-03271 | • RING | 1 | SN: 1279- |
|||
| ? | 07053-10000 | • CAP | 1 | SN: 1279- |
|||
| ? | 07053-00002 | • • GASKET | 1 | SN: 1279- |
|||
| ? | 155-03-11120 | • TANK,LOWER | 1 | SN: 1003- |
|||
| ? | 155-03-11132 | • CORE,RADIATOR ? G-TYPE | 1 | SN: 1279- |
|||
| ? | 155-03-11190 | • CORE,RADIATOR ? D-TYPE | 1 | SN: 1279- |
|||
| ? | 155-03-11140 | • GASKET | 2 | SN: 1003- |
|||
| ? | 155-03-11150 | • PLATE | 4 | SN: 1003- |
|||
| ? | 01010-31025 | • BOLT | 80 | SN: 1003- |
|||
| ? | 01602-01030 | • WASHER,SPRING | 80 | SN: 1003- |
|||
| ? | 155-03-11163 | • SHIELD,L.H. | 1 | SN: 1279- |
|||
| ? | 155-03-11173 | • SHIELD,R.H. | 1 | SN: 1279- |
|||
| ? | 175-03-31490 | • SHIM ? 0.6MM | 8 | SN: 1279- |
|||
| ? | 01010-31025 | • BOLT | 12 | SN: 1279- |
|||
| ? | 01602-01030 | • WASHER,SPRING | 12 | SN: 1279- |
|||
| ? | 155-03-13111 | • OIL COOLER ASS'Y | 1 | SN: 1279- |
|||
| ? | 155-03-11320 | • SHIM | 8 | SN: 1003- |
|||
| ? | 01010-31265 | • BOLT | 16 | SN: 1003- |
|||
| ? | 01602-01236 | • WASHER,SPRING | 16 | SN: 1003- |
|||
| ? | 01010-31225 | • BOLT | 4 | SN: 1003- |
|||
| ? | 01602-01236 | • WASHER,SPRING | 4 | SN: 1003- |
|||
| ? | 155-03-13120 | • TUBE | 1 | SN: 1003- |
|||
| ? | 01010-31045 | • BOLT | 2 | SN: 1003- |
|||
| ? | 01010-31060 | • BOLT | 2 | SN: 1003- |
|||
| ? | 01602-01030 | • WASHER,SPRING | 4 | SN: 1003- |
|||
| ? | 07000-03030 | • O-RING | 2 | SN: 1003- |
|||
| ? | 154-03-11510 | TUBE,OVERFLOW | 1 | SN: 1003- |
|||
| ? | 04059-01010 | WIRE,LOCK | 1 | SN: 1003- |
|||
| ? | 195-03-11690 | CLIP | 4 | SN: 1003- |
|||
| ? | 195-03-00080 | SHIM ASS'Y | 1 | SN: 1279- |
|||
| ? | ☆ | • SHIM ? 0.2MM | 8 | SN: 1279- |
|||
| ? | ☆ | • SHIM ? 1.0MM | 8 | SN: 1279- |
|||
| ? | 01010-31865 | BOLT | 4 | SN: 1003- |
|||
| ? | 01650-01816 | WASHER | 4 | SN: 1003- |
|||
| ? | 155-03-11183 | PROTECTOR | 1 | SN: 1279- |
|||
| ? | 01010-31025 | BOLT | 8 | SN: 1003- |
|||
| ? | 01602-01030 | WASHER,SPRING | 8 | SN: 1003- |
|||
| ? | 01643-01032 | WASHER | 8 | SN: 1003- |
|||
| ? | 154-03-21561 | TUBE,INLET | 1 | SN: 1003- |
|||
| ? | 154-03-21580 | HOSE,INLET | 1 | SN: 1003- |
|||
| ? | 07280-08532 | CLAMP | 3 | SN: 1003- |
|||
| ? | 07000-02070 | O-RING | 1 | SN: 1003- |
|||
| ? | 01010-31235 | BOLT | 2 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 1003- |
|||
| ? | 07040-11612 | PLUG | 1 | SN: 1003- |
|||
| ? | 07005-01612 | GASKET | 1 | SN: 1003- |
|||
| ? | 155-03-12150 | HOSE | 1 | SN: 1063- |
|||
| ? | 08036-01214 | CLIP | 1 | SN: 1003- |
|||
| ? | 01010-31016 | BOLT | 1 | SN: 1003- |
|||
| ? | 01602-01030 | WASHER,SPRING | 1 | SN: 1003- |
|||
| ? | 01643-01032 | WASHER | 1 | SN: 1003- |
|||
| ? | 154-03-11661 | CLAMP | 2 | SN: 1003- |
|||
| ? | 155-03-16150 | TUBE,(FOR REVERSIBLE FAN) | 1 | SN: 1279- |
|||
| ? | 155-03-12160 | TUBE | 1 | SN: 1063- |
|||
| ? | 07000-13035 | O-RING | 1 | SN: 1063- |
|||
| ? | 01010-31030 | BOLT | 2 | SN: 1063- |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 1063- |
|||
| ? | 155-03-12132 | HOSE | 1 | SN: 1063- |
|||
| ? | 154-03-21540 | CLAMP | 2 | SN: 1003- |
|||
| ? | 01010-31220 | BOLT | 2 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 1003- |
|||
| ? | 07280-03826 | CLAMP | 4 | SN: 1279- |
|||
| ? | 155-03-12111 | TUBE,OUTLET | 1 | SN: 1279- |
|||
| ? | 07000-02070 | O-RING | 1 | SN: 1003- |
|||
| ? | 01010-31235 | BOLT | 2 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 1003- |
|||
| ? | 07040-11612 | PLUG | 1 | SN: 1003- |
|||
| ? | 07005-01612 | GASKET | 1 | SN: 1003- |
|||
| ? | 07042-00415 | PLUG | 1 | SN: 1279- |
|||
| ? | 154-03-21580 | HOSE | 1 | SN: 1003- |
|||
| ? | 155-03-12120 | TUBE,OUTLET | 1 | SN: 1003- |
|||
| ? | 07280-08532 | CLAMP | 4 | SN: 1003- |
|||
| ? | 195-03-13241 | VALVE,DRAIN | 1 | SN: 1003- |
|||
| ? | 07000-02070 | O-RING | 1 | SN: 1003- |
|||
| ? | 01010-31235 | BOLT | 2 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 1003- |
|||
| ? | SLAG HANDLING PARTS | ||||||
| ? | 154-03-11511 | TUBE,OVERFLOW (OP) | 1 | SN: 1003- |
