| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 155-63-32103 | DUMP CYLINDER ASS'Y,L.H. | 1 | SN: 1279- |
|||
| ? | □155-63-32102 | DUMP CYLINDER ASS'Y,L.H. | 1 | SN: 1063-1278 |
|||
| ? | 155-63-32101 | DUMP CYLINDER ASS'Y,L.H. | 1 | SN: 1003-1062 |
|||
| ? | 155-63-32203 | DUMP CYLINDER ASS'Y,R.H. | 1 | SN: 1279- |
|||
| ? | 155-63-32202 | DUMP CYLINDER ASS'Y,R.H. | 1 | SN: 1063-1278 |
|||
| ? | 155-63-32201 | DUMP CYLINDER ASS'Y,R.H. | 1 | SN: 1003-1062 |
|||
| ? | 155-63-85142 | • CYLINDER,L.H. | 1 | SN: 1279- |
|||
| ? | □155-63-85141 | • CYLINDER,L.H. | 1 | SN: 1063-1278 |
|||
| ? | 155-63-85140 | • CYLINDER,L.H. | 1 | SN: 1003-1062 |
|||
| ? | 155-63-85242 | • CYLINDER,R.H. | 1 | SN: 1279- |
|||
| ? | 155-63-85241 | • CYLINDER,R.H. | 1 | SN: 1063-1278 |
|||
| ? | 155-63-85240 | • CYLINDER,R.H. | 1 | SN: 1003-1062 |
|||
| ? | 155-63-32132 | • HEAD,CYLINDER | 1 | SN: 1003- |
|||
| ? | (☒155-63-32130) | • HEAD,CYLINDER | 1 | SN: (1003-1062) |
|||
| ? | 07177-07530 | • BUSHING | 1 | SN: 1003- |
|||
| ? | 145-63-22173 | • U-PACKING | 1 | SN: 1003- |
|||
| ? | (☒145-63-22171) | • U-PACKING | 1 | SN: (1003-1278) |
|||
| ? | 07000-15150 | • O-RING | 1 | SN: 1003- |
|||
| ? | 07146-05152 | • RING,BACK-UP | 1 | SN: 1003- |
|||
| ? | 01010-82775 | • BOLT | 4 | SN: 1279- |
|||
| ? | □01010-62775 | • BOLT | 4 | SN: 1003-1278 |
|||
| ? | 01602-22783 | • WASHER,SPRING | 4 | SN: 1279- |
|||
| ? | □01602-02783 | • WASHER,SPRING | 4 | SN: 1003-1278 |
|||
| ? | 221-63-26171 | • GLAND | 1 | SN: 1279- |
|||
| ? | ▩07178-07543 | • GLAND | 1 | SN: 1003-1278 |
|||
| ? | (221-63-26171{01010-51655)} | ||||||
| ? | 07177-07515 | • BUSHING | 1 | SN: 1003- |
|||
| ? | 07016-00758 | • SEAL,DUST | 1 | SN: 1003- |
|||
| ? | 07179-00097 | • RING,SNAP | 1 | SN: 1003- |
|||
| ? | 07000-03095 | • O-RING | 1 | SN: 1279- |
|||
| ? | □07000-13095 | • O-RING | 1 | SN: 1003-1278 |
|||
| ? | 01010-51655 | • BOLT | 2 | SN: 1279- |
|||
| ? | 01010-31650 | • BOLT | 2 | SN: 1003-1278 |
|||
| ? | 01602-21648 | • WASHER,SPRING | 2 | SN: 1279- |
|||
| ? | □01602-01648 | • WASHER,SPRING | 2 | SN: 1003-1278 |
|||
| ? | 155-63-32121 | • ROD,PISTON | 1 | SN: 1003- |
|||
| ? | (☒155-63-32120) | • ROD,PISTON | 1 | SN: (1003-1062) |
|||
| ? | 07143-10707 | • BUSHING | 2 | SN: 1003- |
|||
| ? | 07145-00075 | • SEAL,DUST | 4 | SN: 1003- |
|||
| ? | 155-63-32170 | • PISTON | 1 | SN: 1003- |
|||
| ? | 07155-01640 | • RING,WEAR | 1 | SN: 1003- |
|||
| ? | 141-60-34411 | • U-PACKING | 1 | SN: 1003- |
|||
| ? | (☒141-60-34410) | • U-PACKING | 1 | SN: (1003-1278) |
|||
| ? | 155-63-32270 | • RETAINER | 2 | SN: 1003- |
|||
| ? | 07165-15860 | • NUT | 1 | SN: 1279- |
|||
| ? | □175-63-42381 | • NUT | 1 | SN: 1063-1278 |
|||
| ? | □07165-25860 | • NUT | 1 | SN: 1003-1062 |
|||
| ? | 155-63-32291 | TUBE,R.H. | 1 | SN: 1063- |
|||
| ? | 155-63-32290 | TUBE,R.H. | 1 | SN: 1011-1062 |
|||
| ? | 155-61-11410 | TUBE,R.H. | 1 | SN: 1008-1010 |
|||
| ? | 155-63-32290 | TUBE,R.H. | 1 | SN: 1007-1007 |
|||
| ? | 155-61-11410 | TUBE,R.H. | 1 | SN: 1005-1006 |
|||
| ? | 155-63-32290 | TUBE,R.H. | 1 | SN: 1004-1004 |
|||
| ? | 155-61-11410 | TUBE,R.H. | 1 | SN: 1003-1003 |
|||
| ? | 155-63-32281 | TUBE,L.H. | 1 | SN: 1063- |
|||
| ? | 155-63-32280 | TUBE,L.H. | 1 | SN: 1011-1062 |
|||
| ? | 155-61-11440 | TUBE,L.H. | 1 | SN: 1008-1010 |
|||
| ? | 155-63-32280 | TUBE,L.H. | 1 | SN: 1007-1007 |
|||
| ? | 155-61-11440 | TUBE,L.H. | 1 | SN: 1005-1006 |
|||
| ? | 155-63-32280 | TUBE,L.H. | 1 | SN: 1004-1004 |
|||
| ? | 155-61-11440 | TUBE,L.H. | 1 | SN: 1003-1003 |
|||
| ? | 07000-13038 | O-RING | 2 | SN: 1003- |
|||
| ? | 01010-51065 | BOLT | 8 | SN: 1279- |
|||
| ? | □01010-31065 | BOLT | 8 | SN: 1003-1278 |
|||
| ? | 01602-21030 | WASHER,SPRING | 8 | SN: 1279- |
|||
| ? | □01602-01030 | WASHER,SPRING | 8 | SN: 1003-1278 |
|||
| ? | 07042-00108 | PLUG | 2 | SN: 1003- |
|||
| ? | 155-63-32193 | TUBE,R.H. | 1 | SN: 1279- |
|||
| ? | 155-63-32192 | TUBE,R.H. | 1 | SN: 1230-1278 |
|||
| ? | □155-63-32191 | TUBE,R.H. | 1 | SN: 1063-1229 |
|||
| ? | 155-63-32190 | TUBE,R.H. | 1 | SN: 1011-1062 |
|||
| ? | 155-61-11393 | TUBE,R.H. | 1 | SN: 1008-1010 |
|||
| ? | 155-63-32190 | TUBE,R.H. | 1 | SN: 1007-1007 |
|||
| ? | 155-61-11393 | TUBE,R.H. | 1 | SN: 1005-1006 |
|||
| ? | 155-63-32190 | TUBE,R.H. | 1 | SN: 1004-1004 |
|||
| ? | 155-61-11393 | TUBE,R.H. | 1 | SN: 1003-1003 |
|||
| ? | 155-63-32182 | TUBE,L.H. | 1 | SN: 1230- |
|||
| ? | □155-63-32181 | TUBE,L.H. | 1 | SN: 1063-1229 |
|||
| ? | 155-63-32180 | TUBE,L.H. | 1 | SN: 1011-1062 |
|||
| ? | 155-61-11453 | TUBE,L.H. | 1 | SN: 1008-1010 |
|||
| ? | 155-63-32180 | TUBE,L.H. | 1 | SN: 1007-1007 |
|||
| ? | 155-61-11453 | TUBE,L.H. | 1 | SN: 1005-1006 |
|||
| ? | 155-63-32180 | TUBE,L.H. | 1 | SN: 1004-1004 |
|||
| ? | 155-61-11453 | TUBE,L.H. | 1 | SN: 1003-1003 |
|||
| ? | 07000-13038 | O-RING | 2 | SN: 1003- |
|||
| ? | 01010-51075 | BOLT,L.H. | 8 | SN: 1063- |
|||
| ? | 01010-31065 | BOLT,L.H. | 8 | SN: 1003-1062 |
|||
| ? | 01010-51080 | BOLT,R.H. | 8 | SN: 1279- |
|||
| ? | 01010-51075 | BOLT,R.H. | 8 | SN: 1063-1278 |
|||
| ? | 01010-51065 | BOLT,R.H. | 8 | SN: 1003-1062 |
|||
| ? | 01602-21030 | WASHER,SPRING | 8 | SN: 1279- |
|||
| ? | □01602-01030 | WASHER,SPRING | 8 | SN: 1003-1278 |
|||
| ? | 07042-00108 | PLUG | 2 | SN: 1003- |
|||
| ? | 07282-03411 | CLAMP | 2 | SN: 1003- |
|||
| ? | 01010-51025 | BOLT | 4 | SN: 1279- |
|||
| ? | □01010-31025 | BOLT | 4 | SN: 1003-1278 |
|||
| ? | 01602-21030 | WASHER,SPRING | 4 | SN: 1279- |
|||
| ? | □01602-01030 | WASHER,SPRING | 4 | SN: 1003-1278 |
