| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 09305-11400 | KNOB,COMPRESSION RELEASE LEVER | 1 | SN: 1003- |
|||
| ? | 01582-01411 | NUT | 1 | SN: 1003- |
|||
| ? | 155-43-19310 | LEVER | 1 | SN: 1003- |
|||
| ? | 04010-00732 | KEY | 1 | SN: 1003- |
|||
| ? | 01010-31245 | BOLT | 1 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 1 | SN: 1003- |
|||
| ? | 155-43-19341 | SHAFT | 1 | SN: 1003- |
|||
| ? | 01640-02540 | WASHER | 2 | SN: 1003- |
|||
| ? | 06120-02520 | BEARING,NEEDLE | 2 | SN: 1003- |
|||
| ? | 06122-02504 | SEAL,BEARING | 2 | SN: 1003- |
|||
| ? | 07020-00675 | FITTING,GREASE | 1 | SN: 1003- |
|||
| ? | 155-43-19320 | LEVER | 2 | SN: 1003- |
|||
| ? | 04010-00732 | KEY | 2 | SN: 1003- |
|||
| ? | 01010-31245 | BOLT | 2 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 2 | SN: 1003- |
|||
| ? | 04244-11225 | ROD | 1 | SN: 1003- |
|||
| ? | 04211-01266 | YOKE | 1 | SN: 1003- |
|||
| ? | 01582-01210 | NUT | 1 | SN: 1003- |
|||
| ? | 04205-01235 | PIN,CLEVIS | 2 | SN: 1003- |
|||
| ? | 04050-03020 | PIN,COTTER | 2 | SN: 1003- |
|||
| ? | 155-43-19370 | BRACKET | 1 | SN: 1003- |
|||
| ? | 01010-31230 | BOLT | 4 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 4 | SN: 1003- |
|||
| ? | 01643-01232 | WASHER | 4 | SN: 1003- |
|||
| ? | 155-43-19350 | SHAFT,COMPRESSION RELEASE LEVER | 1 | SN: 1003- |
|||
| ? | 06120-02520 | BEARING,NEEDLE | 2 | SN: 1003- |
|||
| ? | 06122-02504 | SEAL | 4 | SN: 1003- |
|||
| ? | 07020-00675 | FITTING,GREASE | 2 | SN: 1003- |
|||
| ? | 01640-02540 | WASHER | 2 | SN: 1003- |
|||
| ? | 155-43-19330 | LEVER | 1 | SN: 1003- |
|||
| ? | 04010-00732 | KEY | 1 | SN: 1003- |
|||
| ? | 01010-31245 | BOLT | 1 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 1 | SN: 1003- |
|||
| ? | 04248-11227 | ROD | 1 | SN: 1063- |
|||
| ? | ▩04245-01227 | ROD | 1 | SN: 1003-1062 |
|||
| ? | (04248-11227{04250-71265 ?} | ||||||
| ? | 01508-11207) | ||||||
| ? | 04250-51265 | END,ROD | 1 | SN: 1063- |
|||
| ? | 04250-51265 | END,ROD | 2 | SN: 1003-1062 |
|||
| ? | 04250-71265 | END,ROD | 1 | SN: 1063- |
|||
| ? | 01582-01210 | NUT | 1 | SN: 1063- |
|||
| ? | 01582-01210 | NUT | 2 | SN: 1003-1062 |
|||
| ? | 01508-11207 | NUT ? L.H. THREAD | 1 | SN: 1063- |
|||
| ? | 01593-01210 | NUT | 2 | SN: 1003- |
|||
| ? | 04050-03020 | PIN,COTTER | 2 | SN: 1003- |
|||
| ? | 155-43-16781 | LEVER | 1 | SN: 1003- |
|||
| ? | 01010-30830 | BOLT | 1 | SN: 1003- |
|||
| ? | 01602-00825 | WASHER,SPRING | 1 | SN: 1003- |
|||
| ? | 195-43-18360 | SPRING,HOLDER | 1 | SN: 1003- |
|||
| ? | 01010-31020 | BOLT | 2 | SN: 1003- |
|||
| ? | 01602-01030 | WASHER,SPRING | 2 | SN: 1003- |
|||
| ? | 01580-01008 | NUT | 2 | SN: 1087- |
