| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 09304-01240 | KNOB | 1 | SN: 1250- |
|||
| ? | □175-43-28161 | KNOB | 1 | SN: 1003-1249 |
|||
| ? | 155-43-13115 | LEVER,SHIFT | 1 | SN: 1279- |
|||
| ? | ▩155-43-13114 | LEVER,SHIFT | 1 | SN: 1003-1278 |
|||
| ? | (155-43-13115{09361-01460 ?} | ||||||
| ? | 09361-31210) | ||||||
| ? | 09361-31210 | NUT | 1 | SN: 1279- |
|||
| ? | □01582-01210 | NUT | 1 | SN: 1003-1278 |
|||
| ? | 09361-01460 | BUSHING | 1 | SN: 1279- |
|||
| ? | 06120-01612 | BEARING,NEEDLE | 2 | SN: 1003- |
|||
| ? | 06122-01603 | SEAL,BEARING | 2 | SN: 1003- |
|||
| ? | 155-43-13360 | PIN | 1 | SN: 1279- |
|||
| ? | 175-15-26380 | SHAFT | 1 | SN: 1003-1278 |
|||
| ? | 01010-30816 | BOLT | 1 | SN: 1279- |
|||
| ? | 04025-00432 | PIN,ROLL | 1 | SN: 1003-1278 |
|||
| ? | 01650-00808 | WASHER | 1 | SN: 1279- |
|||
| ? | 07020-00675 | FITTING,GREASE | 1 | SN: 1003- |
|||
| ? | 155-43-13122 | YOKE | 1 | SN: 1279- |
|||
| ? | ▩155-43-13121 | YOKE | 1 | SN: 1003-1278 |
|||
| ? | (04064-02012{155-43-13122 ?} | ||||||
| ? | 155-43-13360{01010-30816 ?} | ||||||
| ? | 01650-00808) | ||||||
| ? | 04064-02012 | RING,SNAP | 1 | SN: 1279- |
|||
| ? | 155-43-13380 | BRACKET | 1 | SN: 1383- |
|||
| ? | □155-43-13263 | BRACKET | 1 | SN: 1003-1382 |
|||
| ? | 01010-31235 | BOLT | 6 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 6 | SN: 1003- |
|||
| ? | □01643-01232 | WASHER | 6 | SN: 1003- |
|||
| ? | 155-43-13131 | BRACKET | 1 | SN: 1003- |
|||
| ? | 06120-02016 | BEARING,NEEDLE | 2 | SN: 1003- |
|||
| ? | 06122-02004 | SEAL,BEARING | 4 | SN: 1003- |
|||
| ? | 07020-00675 | FITTING,GREASE | 2 | SN: 1003- |
|||
| ? | 155-43-13370 | LEVER | 1 | SN: 1383- |
|||
| ? | □155-43-13143 | LEVER | 1 | SN: 1003-1382 |
|||
| ? | 01010-30830 | BOLT | 1 | SN: 1003- |
|||
| ? | 01602-00825 | WASHER,SPRING | 1 | SN: 1003- |
|||
| ? | 04010-00516 | KEY | 1 | SN: 1003- |
|||
| ? | 04250-61056 | END,ROD | 1 | SN: 1063- |
|||
| ? | 04250-40056 | END,ROD | 1 | SN: 1003-1062 |
|||
| ? | 01593-01008 | NUT | 1 | SN: 1003- |
|||
| ? | 04050-02018 | PIN,COTTER | 1 | SN: 1003- |
|||
| ? | 04248-11017 | ROD | 1 | SN: 1063- |
|||
| ? | ▩04245-01017 | ROD | 1 | SN: 1003-1062 |
|||
| ? | (04248-11017{04250-61056 ?} | ||||||
| ? | 01508-11006) | ||||||
| ? | 01582-01008 | NUT | 1 | SN: 1063- |
|||
| ? | 01582-01008 | NUT | 2 | SN: 1003-1062 |
|||
| ? | 01508-11006 | NUT ? L.H. THREAD | 1 | SN: 1063- |
|||
| ? | 155-43-13320 | LEVER | 1 | SN: 1003- |
|||
| ? | 01010-30830 | BOLT | 1 | SN: 1003- |
|||
| ? | 01602-00825 | WASHER,SPRING | 1 | SN: 1003- |
|||
| ? | 04010-00516 | KEY | 1 | SN: 1003- |
|||
| ? | 155-43-13213 | LEVER | 1 | SN: 1003- |
|||
| ? | 06120-02016 | BEARING,NEEDLE | 2 | SN: 1003- |
|||
| ? | 06122-02004 | SEAL,BEARING | 2 | SN: 1003- |
|||
| ? | 01640-02032 | WASHER | 1 | SN: 1003- |
|||
| ? | 04064-02012 | RING,SNAP | 1 | SN: 1003- |
|||
| ? | 07020-00675 | FITTING,GREASE | 1 | SN: 1003- |
|||
| ? | 04250-41056 | END,ROD | 2 | SN: 1063- |
|||
| ? | 04250-41056 | END,ROD | 3 | SN: 1003-1062 |
|||
| ? | 04250-61056 | END,ROD | 1 | SN: 1063- |
|||
| ? | 01593-01008 | NUT | 3 | SN: 1003- |
|||
| ? | 04050-02018 | PIN,COTTER | 3 | SN: 1003- |
|||
| ? | 155-43-13340 | ROD | 1 | SN: 1063- |
|||
| ? | ▩04245-01007 | ROD | 1 | SN: 1003-1062 |
|||
| ? | (155-43-13340{04250-61056 ?} | ||||||
| ? | 01508-11006){01508-11006)} | ||||||
| ? | 04245-01006 | ROD | 1 | SN: 1003- |
|||
| ? | 01582-01008 | NUT | 3 | SN: 1063- |
|||
| ? | 01582-01008 | NUT | 4 | SN: 1003-1062 |
|||
| ? | 01508-11006 | NUT ? L.H. THREAD | 1 | SN: 1063- |
|||
| ? | 155-43-13320 | LEVER | 1 | SN: 1003- |
|||
| ? | 01010-30830 | BOLT | 1 | SN: 1003- |
|||
| ? | 01602-00825 | WASHER,SPRING | 1 | SN: 1003- |
|||
| ? | 04010-00516 | KEY | 1 | SN: 1003- |
|||
| ? | 175-43-38260 | GUIDE | 1 | SN: 1279- |
|||
| ? | ▩155-43-13330 | GUIDE | 1 | SN: 1003-1278 |
|||
| ? | (175-43-38260{01225-40816)} | ||||||
| ? | 01225-40816 | SCREW | 4 | SN: 1279- |
|||
| ? | 01220-40816 | SCREW | 4 | SN: 1003-1278 |
|||
| ? | 01602-20825 | WASHER,SPRING | 4 | SN: 1003-1278 |
|||
| ? | 155-43-13193 | CASE | 1 | SN: 1279- |
|||
| ? | □155-43-13192 | CASE | 1 | SN: 1003-1278 |
|||
| ? | 01010-31220 | BOLT | 4 | SN: 1003- |
|||
| ? | 01602-01236 | WASHER,SPRING | 4 | SN: 1003- |
|||
| ? | 09305-00800 | KNOB | 1 | SN: 1279- |
|||
| ? | □145-43-11561 | KNOB | 1 | SN: 1003-1278 |
|||
| ? | 154-843-1250 | LEVER,SAFETY | 1 | SN: 1003- |
|||
| ? | 155-43-17262 | STOPPER | 1 | SN: 1003- |
|||
| ? | 154-44-22430 | SHAFT | 1 | SN: 1003- |
|||
| ? | 170-33-11330 | BUSHING | 1 | SN: 1003- |
|||
| ? | 04025-00532 | PIN | 1 | SN: 1003- |
|||
| ? | 04244-10811 | ROD | 1 | SN: 1003- |
|||
| ? | 04211-00844 | YOKE | 1 | SN: 1003- |
|||
| ? | 01580-00806 | NUT | 1 | SN: 1003- |
|||
| ? | 04205-00822 | PIN | 2 | SN: 1003- |
|||
| ? | 04050-02012 | PIN,COTTER | 2 | SN: 1003- |
|||
| ? | 175-43-38280 | SHAFT | 1 | SN: 1303- |
|||
| ? | □154-44-22460 | SHAFT | 1 | SN: 1003-1302 |
|||
| ? | 04025-00532 | PIN | 1 | SN: 1003- |
|||
| ? | 154-44-22470 | SHAFT | 1 | SN: 1003- |
|||
| ? | 04025-00532 | PIN | 1 | SN: 1003- |
|||
| ? | 154-44-12460 | SPRING | 1 | SN: 1003- |
