| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (154-13-31004) | TORQUE CONVERTER A.,TCS41-8D | 1 | SN: K1367- |
|||
| ? | 154-13-31123 | • PUMP | 1 | SN: K1367- |
|||
| ? | 154-13-41140 | • GEAR | 1 | SN: K1367- |
|||
| ? | 06032-01017 | • BEARING | 1 | SN: K1367- |
|||
| ? | 154-13-41180 | • PLATE | 1 | SN: K1367- |
|||
| ? | 01010-51025 | • BOLT | 12 | SN: K1367- |
|||
| ? | 154-13-41150 | • PLATE,LOCK | 6 | SN: K1367- |
|||
| ? | 01010-61035 | • BOLT | 30 | SN: K1367- |
|||
| ? | 01602-21030 | • WASHER,SPRING | 30 | SN: K1367- |
|||
| ? | 01643-31032 | • WASHER | 30 | SN: K1367- |
|||
| ? | 07040-11007 | • PLUG | 2 | SN: K1367- |
|||
| ? | 154-13-00010 | • CASE ASS'Y | 1 | SN: K1367- |
|||
| ? | 154-13-41210 | • • CASE | 1 | SN: K1367- |
|||
| ? | 195-13-11220 | • • GEAR | 1 | SN: K1367- |
|||
| ? | 01010-61230 | • • BOLT | 12 | SN: K1367- |
|||
| ? | 195-13-11230 | • • PLATE,LOCK | 6 | SN: K1367- |
|||
| ? | 04020-01228 | • • PIN,DOWEL | 2 | SN: K1367- |
|||
| ? | 154-13-11240 | • BEARING | 1 | SN: K1367- |
|||
| ? | 154-13-11252 | • PILOT | 1 | SN: K1367- |
|||
| ? | 01010-51230 | • BOLT | 8 | SN: K1367- |
|||
| ? | 195-13-11261 | • PLATE,LOCK | 4 | SN: K1367- |
|||
| ? | 154-13-41510 | • TURBINE ASS'Y | 1 | SN: K1367- |
|||
| ? | ☆ | • • TURBINE | 1 | SN: K1367- |
|||
| ? | ☆ | • • BOSS | 1 | SN: K1367- |
|||
| ? | ☆ | • • PLATE | 1 | SN: K1367- |
|||
| ? | ☆ | • • RIVET | 16 | SN: K1367- |
|||
| ? | 154-13-11660 | • COUPLING ASS'Y | 1 | SN: K1367- |
|||
| ? | ☆ | • • COUPLING | 1 | SN: K1367- |
|||
| ? | ☆ | • • COVER | 1 | SN: K1367- |
|||
| ? | 07020-00001 | • FITTING | 1 | SN: K1367- |
|||
| ? | 154-13-41650 | • SHAFT | 1 | SN: K1367- |
|||
| ? | 07000-32055 | • O-RING | 1 | SN: K1367- |
|||
| ? | 154-13-11750 | • SEAT,SEAL | 1 | SN: K1367- |
|||
| ? | 154-13-13360 | • BEARING | 1 | SN: K1367- |
|||
| ? | 154-13-11730 | • SPACER | 1 | SN: K1367- |
|||
| ? | 04064-06020 | • RING,SNAP | 1 | SN: K1367- |
|||
| ? | 175-13-21720 | • RING,SEAL | 1 | SN: K1367- |
|||
| ? | 175-13-21691 | • HOLDER | 1 | SN: K1367- |
|||
| ? | 175-13-21711 | • PLATE,LOCK | 1 | SN: K1367- |
|||
| ? | 175-13-21810 | • BOLT,REAMER | 2 | SN: K1367- |
|||
| ? | 154-13-32112 | • STATOR | 1 | SN: K1367- |
|||
| ? | 154-13-42120 | • RACE | 1 | SN: K1367- |
|||
| ? | 01010-51030 | • BOLT | 12 | SN: K1367- |
|||
| ? | 01643-31032 | • WASHER | 12 | SN: K1367- |
|||
| ? | 154-13-42520 | • SHAFT | 1 | SN: K1367- |
|||
| ? | 04064-08025 | • RING,SNAP | 1 | SN: K1367- |
|||
| ? | 154-13-42710 | • RING,SEAL | 1 | SN: K1367- |
|||
| ? | 07000-65190 | • O-RING | 1 | SN: K1367- |
|||
| ? | 01010-51235 | • BOLT | 6 | SN: K1367- |
|||
| ? | 01602-21236 | • WASHER,SPRING | 6 | SN: K1367- |
|||
| ? | 154-13-12722 | • HOUSING | 1 | SN: K1367- |
|||
| ? | 07000-62310 | • O-RING | 1 | SN: K1367- |
|||
| ? | 154-13-11610 | • SHIM ? 0.05MM | 1 | SN: K1367- |
|||
| ? | 154-13-11620 | • SHIM ? 0.10MM | 1 | SN: K1367- |
|||
| ? | 154-13-11630 | • SHIM ? 0.30MM | 1 | SN: K1367- |
|||
| ? | 07011-10075 | • SEAL,OIL | 1 | SN: K1367- |
|||
| ? | 175-13-22730 | • SEAL | 1 | SN: K1367- |
|||
| ? | 01010-51235 | • BOLT | 6 | SN: K1367- |
|||
| ? | 01602-21236 | • WASHER,SPRING | 6 | SN: K1367- |
|||
| ? | 154-13-05020 | SHIM KIT | 1 | SN: K1367- |
|||
| ? | 154-13-11610 | • SHIM ? 0.05MM | 1 | SN: K1367- |
|||
| ? | 154-13-11620 | • SHIM ? 0.10MM | 2 | SN: K1367- |
|||
| ? | 154-13-11630 | • SHIM ? 0.30MM | 1 | SN: K1367- |
