| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 141-27-32230 | SHAFT | 2 | SN: 20024- |
|||
| ? | 141-27-32131 | SHAFT | 2 | SN: 20006-20021 |
|||
| ? | 141-27-32240 | NUT | 2 | SN: 20006- |
|||
| ? | 170-27-12480 | RING | 2 | SN: 20006- |
|||
| ? | 130-27-12131 | PIN | 2 | SN: 20006- |
|||
| ? | 06030-23220 | BEARING | 2 | SN: 28169- |
|||
| ? | 140-09-13420 | BEARING | 2 | SN: 20006-28168 |
|||
| ? | 141-27-12640 | COLLAR | 2 | SN: 20006- |
|||
| ? | 145-27-32430 | RETAINER | 2 | SN: 20006- |
|||
| ? | 07000-05170 | O-RING | 2 | SN: 20006- |
|||
| ? | 01010-31230 | BOLT | 16 | SN: 20006- |
|||
| ? | 01602-01236 | WASHER | 16 | SN: 20006- |
|||
| ? | 150-27-00015 | FLOATING SEAL ASS'Y | 2 | SN: 20006- |
|||
| ? | 150-27-00190 | • O-RING ASS'Y | 1 | SN: 20006- |
|||
| ? | ☆ | • • O-RING | 2 | SN: 20006- |
|||
| ? | 150-27-00180 | • SEAL RING ASS'Y | 1 | SN: 20006- |
|||
| ? | ☆ | • • RING,SEAL | 2 | SN: 20006- |
|||
| ? | 141-27-32160 | BEARING | 2 | SN: 20006- |
|||
| ? | 01010-32465 | BOLT | 8 | SN: 22388- |
|||
| ? | □01040-32465 | BOLT | 8 | SN: 20006-22387 |
|||
| ? | 01602-02472 | WASHER | 8 | SN: 20006- |
|||
| ? | 141-27-32190 | BUSHING | 2 | SN: 20006- |
|||
| ? | 04000-01065 | KEY | 2 | SN: 20006- |
|||
| ? | 145-27-32450 | WASHER | 2 | SN: 20006- |
|||
| ? | 135-27-12320 | LOCK | 2 | SN: 20006- |
|||
| ? | 131-27-51110 | NUT | 2 | SN: 22388- |
|||
| ? | 145-27-12330 | NUT | 2 | SN: 20006-22387 |
|||
| ? | 145-27-32461 | CAP | 2 | SN: 20006- |
|||
| ? | 07000-03130 | O-RING | 2 | SN: 20006- |
|||
| ? | 01010-31845 | BOLT | 8 | SN: 22388- |
|||
| ? | □01040-31845 | BOLT | 8 | SN: 20006-22387 |
|||
| ? | 01602-01854 | WASHER | 8 | SN: 20006- |
|||
| ? | 145-27-41210 | PINION | 2 | SN: 28971- |
|||
| ? | 141-27-31143 | PINION | 2 | SN: 20054-28970 |
|||
| ? | 141-27-31142 | PINION | 2 | SN: 20032-20053 |
|||
| ? | 141-27-31141 | PINION | 2 | SN: 20006-20031 |
|||
| ? | 145-27-41221 | BEARING | 2 | SN: 31272- |
|||
| ? | □145-27-41220 | BEARING | 2 | SN: 28971-31271 |
|||
| ? | 130-09-13550 | BEARING | 2 | SN: 20006-28970 |
|||
| ? | 145-27-41231 | BEARING | 2 | SN: 31272- |
|||
| ? | □145-27-41230 | BEARING | 2 | SN: 28971-31271 |
|||
| ? | 06043-02311 | BEARING | 2 | SN: 28169-28970 |
|||
| ? | 140-09-13110 | BEARING | 2 | SN: 20006-28168 |
|||
| ? | 141-27-31193 | FLANGE | 2 | SN: 20054- |
|||
| ? | 141-27-31190 | FLANGE | 2 | SN: 20006-20053 |
|||
| ? | 01010-31430 | BOLT | 16 | SN: 22388- |
|||
| ? | □01040-31430 | BOLT | 16 | SN: 20006-22387 |
|||
| ? | 01602-01442 | WASHER | 16 | SN: 20006- |
|||
| ? | 131-27-51120 | BOLT | 2 | SN: 22388- |
|||
| ? | 145-27-11230 | BOLT | 2 | SN: 20006-22387 |
|||
| ? | 130-27-51140 | LOCK | 2 | SN: 20054- |
|||
| ? | 130-27-11655 | WASHER | 2 | SN: 20006-20053 |
|||
| ? | 130-27-51151 | NUT | 2 | SN: 22388- |
|||
| ? | 130-27-51150 | NUT | 2 | SN: 20054-22387 |
|||
| ? | 130-27-11630 | NUT | 2 | SN: 20006-20053 |
|||
| ? | 145-27-11240 | GASKET | 2 | SN: 20006- |
|||
| ? | 141-27-31132 | CAGE | 2 | SN: 20006- |
|||
| ? | 07013-00090 | SEAL | 2 | SN: 20006- |
|||
| ? | 07000-05165 | O-RING | 2 | SN: 20006- |
|||
| ? | 01010-31235 | BOLT | 12 | SN: 20006- |
|||
| ? | 01602-01236 | WASHER | 12 | SN: 20006- |
|||
| ? | 145-27-41320 | GEAR | 2 | SN: 28971- |
|||
| ? | (☒145-27-41310) | GEAR | 2 | SN: (28971-.) |
|||
| ? | 141-27-31151 | GEAR | 2 | SN: 20006-28970 |
|||
| ? | 141-27-31180 | KEY | 6 | SN: 20006- |
|||
| ? | 141-27-31170 | SPACER | 2 | SN: 20006- |
|||
| ? | 145-27-41430 | PINION | 2 | SN: 28873- |
|||
| ? | (☒145-27-41410) | PINION | 2 | SN: (28873-.) |
|||
| ? | 141-27-31162 | PINION | 2 | SN: 26096-28872 |
|||
| ? | ▩141-27-31161 | PINION | 2 | SN: 20006-26095 |
|||
| ? | (141-27-31162{140-09-13131 ?} | ||||||
| ? | 141-27-31310{141-27-31320 ?} | ||||||
| ? | 141-27-31330{01653-02216 ?} | ||||||
| ? | 01583-02213{04020-00820(2))} | ||||||
| ? | 140-09-13131 | BEARING | 2 | SN: 28971- |
|||
| ? | 140-09-13120 | BEARING | 2 | SN: 20006-28970 |
|||
| ? | 140-09-13131 | BEARING | 2 | SN: 26096- |
|||
| ? | 140-09-13130 | BEARING | 2 | SN: 20006-26095 |
|||
| ? | 141-27-31310 | HOLDER | 2 | SN: 26096- |
|||
| ? | 141-27-31320 | SHAFT | 2 | SN: 26096- |
|||
| ? | 01653-22216 | WASHER | 2 | SN: 26096- |
|||
| ? | 01583-02213 | NUT | 2 | SN: 26096- |
|||
| ? | 04020-00820 | PIN | 4 | SN: 26096- |
|||
| ? | 141-27-31330 | SPACER | 2 | SN: 26096-28167 |
