| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 142-06-13621 | WIRE ASS'Y | 1 | SN: 1305- |
|||
| ? | 142-06-13620 | WIRE ASS'Y | 1 | SN: 1001-1304 |
|||
| ? | 142-06-13641 | WIRE ASS'Y | 1 | SN: 1305- |
|||
| ? | 142-06-13640 | WIRE ASS'Y | 1 | SN: 1001-1304 |
|||
| ? | 142-06-13651 | WIRE ASS'Y | 1 | SN: 1305- |
|||
| ? | 142-06-13650 | WIRE ASS'Y | 1 | SN: 1001-1304 |
|||
| ? | 22W-06-13430 | • DIODE | 1 | SN: 1001- |
|||
| ? | 08166-02470 | BUZZER | 1 | SN: 1946- |
|||
| ? | □08166-02480 | BUZZER | 1 | SN: 1001-1945 |
|||
| ? | 01220-40625 | SCREW | 1 | SN: 1001- |
|||
| ? | 01220-40616 | SCREW | 2 | SN: 1001- |
|||
| ? | 01580-10605 | NUT | 3 | SN: 1001- |
|||
| ? | 01602-20619 | WASHER,SPRING | 3 | SN: 1001- |
|||
| ? | 01640-20610 | WASHER | 3 | SN: 1001- |
|||
| ? | 08064-10000 | HORN SWITCH,HORN | 1 | SN: 1001- |
|||
| ? | 142-06-13740 | COVER | 2 | SN: 1001- |
|||
| ? | 113-06-23220 | COVER | 2 | SN: 1001-1304 |
|||
| ? | 08034-00519 | BAND | 4 | SN: 1305- |
|||
| ? | 08034-00519 | BAND | 8 | SN: 1001-1304 |
|||
| ? | 142-06-13570 | BRACKET | 1 | SN: 1001- |
|||
| ? | 01010-51025 | BOLT | 2 | SN: 1001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 2 | SN: 1001- |
|||
| ? | 08052-12711 | CLIP | 1 | SN: .- |
|||
| ? | □142-06-15340 | CLIP | 1 | SN: 1305-. |
|||
| ? | 142-06-13540 | CLIP | 1 | SN: 1001-1304 |
|||
| ? | 08036-01814 | CLIP | 3 | SN: 1305- |
|||
| ? | 198-904-4280 | CLIP | 3 | SN: 1001-1304 |
|||
| ? | 22W-06-21410 | CLIP | 1 | SN: 1305- |
|||
| ? | 08036-01414 | CLIP | 1 | SN: 1001-1304 |
|||
| ? | 22W-06-21410 | CLIP | 3 | SN: 1305- |
|||
| ? | 281-01-13180 | CLIP | 3 | SN: 1001-1304 |
|||
| ? | 22W-06-21410 | CLIP | 2 | SN: 1305- |
|||
| ? | 140-06-18310 | CLIP | 2 | SN: 1001-1304 |
|||
| ? | 08034-00823 | BAND | 12 | SN: 1305- |
|||
| ? | 142-06-13530 | CLIP | 1 | SN: 1001- |
|||
| ? | 01010-51020 | BOLT | 6 | SN: 1001- |
|||
| ? | 01010-51025 | BOLT | 5 | SN: 1001- |
|||
| ? | 01602-21030 | WASHER,SPRING | 11 | SN: 1001- |
|||
| ? | 01643-31032 | WASHER | 11 | SN: 1001- |
|||
| ? | 21T-62-25740 | CLIP | 1 | SN: 1001- |
|||
| ? | 08036-01414 | CLIP | 2 | SN: 1305- |
|||
| ? | 175-04-25390 | CLIP | 2 | SN: 1001-1304 |
|||
| ? | 01010-50816 | BOLT | 2 | SN: 1001- |
|||
| ? | 01602-20825 | WASHER,SPRING | 2 | SN: 1001- |
|||
| ? | 01643-30823 | WASHER | 2 | SN: 1001- |
