| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | ND448800-5251 | COOLING ASS'Y | 1 | SN: 50501- |
|||
| ? | ND245420-8601 | • CASE ASS'Y | 1 | SN: 50501- |
|||
| ? | ND447600-3911 | • EVAPORATOR ASS'Y | 1 | SN: 50501- |
|||
| ? | ND949142-0020 | • • O-RING | 1 | SN: 50501- |
|||
| ? | ND447500-0180 | • VALVE,EXPANSION | 1 | SN: 50501- |
|||
| ? | ND145511-0040 | • HOLDER,REMOTE VALVE | 1 | SN: 50501- |
|||
| ? | 205-979-7100 | • PACKING | 1 | SN: 50501- |
|||
| ? | ND446860-8230 | • TUBE | 1 | SN: 50501- |
|||
| ? | ND949142-0010 | • • O-RING | 3 | SN: 50501- |
|||
| ? | ND443440-0050 | • • SWITCH,PRESSURE | 1 | SN: 50501- |
|||
| ? | ND077500-2580 | • THERMISTOR | 1 | SN: 50501- |
|||
| ? | ND146690-5360 | • CLAMP | 1 | SN: 50501- |
|||
| ? | ND113622-0200 | • COVER | 1 | SN: 50501- |
|||
| ? | ND116420-0790 | • RADIATOR | 1 | SN: 50501- |
|||
| ? | ND245420-8610 | • CASE ASS'Y | 1 | SN: 50501- |
|||
| ? | ND949001-1730 | • SCREW,TAPPING | 6 | SN: 50501- |
|||
| ? | ND113650-0703 | • ROTARY WATER VALVE | 1 | SN: 50501- |
|||
| ? | ND113600-8512 | • • VALVE,WATER | 1 | SN: 50501- |
|||
| ? | ND017264-9300 | • • HOSE,WATER | 1 | SN: 50501- |
|||
| ? | ND949351-0860 | • • CLIP,HOSE | 3 | SN: 50501- |
|||
| ? | ND017441-4330 | • • PIPE,WATER | 1 | SN: 50501- |
|||
| ? | ND7052-200450 | • • HOSE,WATER | 1 | SN: 50501- |
|||
| ? | 195-979-4240 | • • CLAMP | 1 | SN: 50501- |
|||
| ? | ND113621-2951 | • • BRACKET | 1 | SN: 50501- |
|||
| ? | ND949001-2500 | • • SCREW,TAPPING | 2 | SN: 50501- |
|||
| ? | ND949351-0860 | • CLIP,HOSE | 1 | SN: 50501- |
|||
| ? | ND90930-05161 | • SCREW,TAPPING | 2 | SN: 50501- |
|||
| ? | ND246780-4220 | • CLAMP,PIPING | 1 | SN: 50501- |
|||
| ? | ND246780-4000 | • CLAMP,PIPING | 1 | SN: 50501- |
|||
| ? | ND949001-2690 | • SCREW,TAPPING | 4 | SN: 50501- |
|||
| ? | ND146532-2930 | • BRACKET | 1 | SN: 50501- |
|||
| ? | ND146532-2940 | • BRACKET | 1 | SN: 50501- |
|||
| ? | ND146532-2950 | • BRACKET | 1 | SN: 50501- |
|||
| ? | ND063700-6280 | • MOTOR | 1 | SN: 50501- |
|||
| ? | ND116291-1690 | • FLANGE | 1 | SN: 50501- |
|||
| ? | ND116662-1860 | • SHAFT | 1 | SN: 50501- |
|||
| ? | ND146690-9730 | • CLAMP | 2 | SN: 50501- |
|||
| ? | ND246680-2810 | • CLAMP,PIPING | 1 | SN: 50501- |
|||
| ? | ND90940-05121 | • SCREW,TAPPING | 5 | SN: 50501- |
|||
| ? | ND90930-05208 | • SCREW,TAPPING | 3 | SN: 50501- |
