| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6742-01-1000 | GASKET | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-2620 | TUBE.OIL SUCTION | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-2630 | BOLT | 2 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-2640 | SPACER | 2 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-2650 | BRACKET | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6732-21-4180 | BOLT | 3 | Field_1: Field_2: 45343246- |
|||
| ? | 6732-21-5180 | WASHER | 32 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-2660 | NUT | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-0970 | GASKET | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-2670 | PAN.OIL | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6732-21-6610 | BOLT | 32 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-2680 | WASHER.SPRING | 32 | Field_1: Field_2: 45343246- |
|||
| ? | 6732-21-5190 | GASKET | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6732-21-5250 | PLUG | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6742-01-2690 | WASHER | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6732-21-5540 | PLUG | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6732-21-5220 | PLUG | 1 | Field_1: Field_2: 45343246- |
|||
| ? | 6732-21-5170 | GASKET.SEAL | 1 | Field_1: Field_2: 45343246- |
