Содержание Wheel Loaders Komatsu WA380-DZ-3 Serial No.10580 and up(wa3803cn)
CYLINDER BLOCK(|000016 : |A0015)
Номер на схеме Каталожный номер Название Количество Детали
? 6742-01-1340 CYLINDER BLOCK ASS'Y 1
Field_1:
Field_2: 45343246-
? ☆ • BLOCK.CYLINDER 1
Field_1:
Field_2: 45343246-
? 6742-01-1360 • PLUG.EXPANSION 1
Field_1:
Field_2: 45343246-
? 6742-01-1370 • PLUG.EXPANSION 4
Field_1:
Field_2: 45343246-
? 6742-01-1380 • PLUG.EXPANSION 2
Field_1:
Field_2: 45343246-
? 6742-01-1390 • PLUG.EXPANSION 1
Field_1:
Field_2: 45343246-
? 6742-01-1400 • BUSHING.CAMSHAFT 7
Field_1:
Field_2: 45343246-
? 6742-01-1410 • CAP.MAIN BEARING 7
Field_1:
Field_2: 45343246-
? 6742-01-1420 • PLUG.EXPANSION 4
Field_1:
Field_2: 45343246-
? 6742-01-1430 • BOLT 14
Field_1:
Field_2: 45343246-
? 6742-01-1440 KIT.CYLINDER BLOCK 1
Field_1:
Field_2: 45343246-
? 6732-21-1830 • PLUG.EXPANSION 1
Field_1:
Field_2: 45343246-
? 6742-01-1450 • VALVE.DRAIN 1
Field_1:
Field_2: 45343246-
? 6735-21-5530 • PLUG.EXPANSION 2
Field_1:
Field_2: 45343246-
? 6732-11-1910 • PLUG 4
Field_1:
Field_2: 45343246-
? 6732-11-1920 • PLUG 2
Field_1:
Field_2: 45343246-
? 6742-01-1460 • PLUG 1
Field_1:
Field_2: 45343246-
? 6732-21-6120 • PIN.DOWEL 2
Field_1:
Field_2: 45343246-
? 6732-01-1470 • PIN.DOWEL 4
Field_1:
Field_2: 45343246-
? 6742-01-1480 • PLUG.EXPANSION 1
Field_1:
Field_2: 45343246-
? 6742-01-1490 • NOZZLE.PISTON COOLING 12
Field_1:
Field_2: 45343246-
? 6732-11-1930 • PLUG 6
Field_1:
Field_2: 45343246-
? 6742-01-1500 KIT.LINER 6
Field_1:
Field_2: 45343246-
? ☆ • LINER.CYLINDER 1
Field_1:
Field_2: 45343246-
? 6742-01-1520 • SEAL.RING 1
Field_1:
Field_2: 45343246-
? COUNTERBORE
Field_1:
Field_2:
? 6742-01-1530 SHIM.0.25MM A/R
Field_1:
Field_2: 45343246-
? 6742-01-1540 SHIM.0.38MM A/R
Field_1:
Field_2: 45343246-
? 6742-01-1550 SHIM.0.50MM A/R
Field_1:
Field_2: 45343246-
? SERVICE PARTS
Field_1:
Field_2:
? 6742-01-1560 BUSHING.CAMSHAFT A/R
Field_1:
Field_2: 45343246-

Wheel Loaders Komatsu / WA380-DZ-3 Serial No.10580 and up(wa3803cn) / CYLINDER BLOCK(|000016 : |A0015)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
