| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 104-60-41500 | VALVE ASS'Y | 1 | SN: 78604- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1680-41A0 TO Y1680-45A0. | ||||||
| ? | NAD33217152101 | • BLOCK | 1 | SN: 78604- |
|||
| ? | (NAD33420697301) | • VALVE SUB ASS'Y,(SEE FIG. Y1680-42A0) | 1 | SN: 78604- |
|||
| ? | (NAD33420693001) | • VALVE SUB ASS'Y,(SEE FIG. Y1680-43A0) | 1 | SN: 78604- |
|||
| ? | NAD33214825301 | • BLOCK | 1 | SN: 78604- |
|||
| ? | NAC01200055010 | • O-RING | 1 | SN: 78604- |
|||
| ? | NAB01011008004 | • NUT | 8 | SN: 78604- |
|||
| ? | NAE51413047142 | • STUD | 4 | SN: 78604- |
|||
| ? | NAD33416984001 | • PLUG ASS'Y | 1 | SN: 78604- |
|||
| ? | 07040-11007 | • • PLUG | 1 | SN: 78604- |
|||
| ? | 07002-11023 | • • O-RING | 1 | SN: 78604- |
|||
| ? | (NAD33314757324) | • VALVE ASS'Y,(SEE FIG. Y1680-44A0) | 1 | SN: 78604- |
|||
| ? | NAD33420239001 | • VALVE ASS'Y | 1 | SN: 78604- |
|||
| ? | (NAD33416379421) | • VALVE ASS'Y,SAFETY (SEE FIG. Y1680-45A0) | 2 | SN: 78604- |
