| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-43-19140 | PLATE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 363-06-31121 | SWITCH.BOOM KICK OUT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01225 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 421-43-19131 | PLATE | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01220 | BOLT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 08053-01512 | CLIP | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 421-43-19223 | PLATE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 363-06-31121 | SWITCH.BUCKET POSITIONER | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01010-81235 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01643-31232 | WASHER | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01642-21216 | WASHER | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01643-31232 | WASHER | 1 | Field_1: 25001- Field_2: |
|||
| ? | 08053-01510 | CLIP | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 421-88-01232 | PLATE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01235 | BOLT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 6113-63-1630 | SHIM.0.3MM | 2 | Field_1: 25001- Field_2: |
|||
| ? | 6113-63-1640 | SHIM.0.5MM | 2 | Field_1: 25001- Field_2: |
