| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-62-13265 | TUBE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-13275 | TUBE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07042-30108 | PLUG | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07000-13045 | O-RING | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01010-81245 | BOLT | 8 | Field_1: 25001- Field_2: |
|||
| ? | 01643-51232 | WASHER | 8 | Field_1: 25001- Field_2: |
|||
| ? | 07124-01211 | HOSE | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07000-13038 | O-RING | 4 | Field_1: 25001- Field_2: |
|||
| ? | 07371-31255 | FLANGE SPLIT | 8 | Field_1: 25001- Field_2: |
|||
| ? | 07372-21035 | BOLT | 16 | Field_1: 25001- Field_2: |
|||
| ? | 01643-51032 | WASHER | 16 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-13153 | TUBE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-13035 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01010-81060 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 01643-51032 | WASHER | 4 | Field_1: 25001- Field_2: |
|||
| ? | 205-62-54460 | CLAMP | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01245 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-23170 | BRACKET.L.H | 1 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-23180 | BRACKET.R.H | 1 | Field_1: 25001- Field_2: |
|||
| ? | 415-64-13130 | CUSHION | 4 | Field_1: 25001- Field_2: |
|||
| ? | 419-43-17930 | CUSHION | 4 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-18560 | SPACER | 4 | Field_1: 25001- Field_2: |
|||
| ? | 415-64-13120 | WASHER | 8 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01045 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 07283-34354 | CLIP | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07283-54353 | SEAT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01599-01011 | NUT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: 25001- Field_2: |
