| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 07042-30108 | PLUG | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07221-20628 | NUT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07222-00616 | PLUG | 1 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-23510 | TUBE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-12060 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01275 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 07122-01416 | HOSE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-13048 | O-RING | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07371-31465 | FLANGE.SPLIT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 07372-21240 | BOLT | 8 | Field_1: 25001- Field_2: |
|||
| ? | 01643-51232 | WASHER | 8 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-23320 | TUBE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-13048 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01240 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-23160 | PLATE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01030 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07283-34354 | CLIP | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07283-54353 | SEAT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01597-01009 | NUT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: 25001- Field_2: |
