| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-62-23240 | TUBE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-13045 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01275 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 07125-01215 | HOSE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-13038 | O-RING | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07371-31255 | FLANGE SPLIT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 07372-21035 | BOLT | 8 | Field_1: 25001- Field_2: |
|||
| ? | 01643-51032 | WASHER | 8 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-23110 | TUBE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-13045 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01275 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-Z3150 | PLATE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01030 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-23290 | BRACKET | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01010-81030 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01025 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07283-34354 | CLIP | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07283-54353 | SEAT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01597-01009 | NUT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: 25001- Field_2: |
|||
| ? | 08210-02908 | SPIRAL TUBE | 1 | Field_1: 25139- Field_2: |
