| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-60-25122 | TANK | 1 | Field_1: 25001- Field_2: |
|||
| ? | 421-60-11622 | GAUGE,SIGHT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07002-15234 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 419-60-Z5230 | BREATHER ASS'Y | 1 | Field_1: 25001- Field_2: |
|||
| ? | 285-62-17320 | • ELEMENT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 419-60-15370 | • O-RING | 2 | Field_1: 25001- Field_2: |
|||
| ? | 419-60-15380 | • O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 419-60-15390 | • O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 424-60-15220 | • RING,SNAP | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07051-01000 | CAP | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07051-00003 | • GASKET | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07063-01142 | ELEMENT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 419-60-25410 | VALVE ASS'Y | 2 | Field_1: 25001- Field_2: |
|||
| ? | 195-60-16330 | SPRING | 2 | Field_1: 25001- Field_2: |
|||
| ? | 195-60-16242 | COVER | 2 | Field_1: 25001- Field_2: |
|||
| ? | 424-60-15150 | PLUG | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07000-12010 | O-RING | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07000-15175 | O-RING | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01230 | BOLT | 8 | Field_1: 25001- Field_2: |
|||
| ? | 428-04-11120 | COVER | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-15200 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01020 | BOLT | 6 | Field_1: 25001- Field_2: |
|||
| ? | 425-60-15230 | COVER | 1 | Field_1: 25001- Field_2: |
|||
| ? | 426-60-15150 | VALVE ASS'Y | 1 | Field_1: 25001- Field_2: |
|||
| ? | 6693-22-5610 | • BODY | 1 | Field_1: 25001- Field_2: |
|||
| ? | 6693-22-5620 | • VALVE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 04020-00514 | • PIN,DOWEL | 1 | Field_1: 25001- Field_2: |
|||
| ? | 426-60-15160 | • PLUG | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-73028 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01025 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07000-15200 | O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01020 | BOLT | 6 | Field_1: 25001- Field_2: |
|||
| ? | 421-60-25310 | BRACKET | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01010-81640 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 01010-81635 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01643-31645 | WASHER | 6 | Field_1: 25001- Field_2: |
|||
| ? | 01010-81645 | BOLT | 3 | Field_1: 25001- Field_2: |
|||
| ? | 01580-01613 | NUT | 3 | Field_1: 25001- Field_2: |
|||
| ? | 01643-31645 | WASHER | 6 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01220 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 07042-70108 | PLUG | 1 | Field_1: 25001- Field_2: |
