| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (705-52-40150) | PUMP ASS'Y(SAR112+28) | 1 | Field_1: 25001- Field_2: |
|||
| ? | 705-36-29540 | • PUMP ASS'Y(SAR28) | 1 | Field_1: 25001- Field_2: |
|||
| ? | (★705-19-01710) | • • BRACKET | 1 | Field_1: 25001- Field_2: |
|||
| ? | (★705-17-01351) | • • • BUSHING PLANE | 2 | Field_1: 25001- Field_2: |
|||
| ? | (★705-18-29110) | • • CASE GEAR | 1 | Field_1: 25001- Field_2: |
|||
| ? | (★705-17-01121) | • • COVER | 1 | Field_1: 25001- Field_2: |
|||
| ? | (★705-17-01351) | • • • BUSHING PLANE | 2 | Field_1: 25001- Field_2: |
|||
| ? | (★705-18-29750) | • • GEAR DRIVE | 1 | Field_1: 25001- Field_2: |
|||
| ? | (★705-18-29810) | • • GEAR DRIVEN | 1 | Field_1: 25001- Field_2: |
|||
| ? | 705-17-01610 | • • PLATE SIDE | 2 | Field_1: 25001- Field_2: |
|||
| ? | 705-67-01440 | • • RING BACK-UP | 2 | Field_1: 25001- Field_2: |
|||
| ? | 705-67-01470 | • • RING SEAL | 2 | Field_1: 25001- Field_2: |
|||
| ? | 705-67-01380 | • • O-RING | 2 | Field_1: 25001- Field_2: |
|||
| ? | 04020-00820 | • • PIN DOWEL | 4 | Field_1: 25001- Field_2: |
|||
| ? | 04020-01228 | • • PIN DOWEL | 2 | Field_1: 25001- Field_2: |
|||
| ? | 705-17-02760 | • • BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 01643-51232 | • • WASHER | 4 | Field_1: 25001- Field_2: |
|||
| ? | 705-19-01330 | • COUPLING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 705-17-04481 | • O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 705-19-03470 | • BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 705-17-04980 | • WASHER | 4 | Field_1: 25001- Field_2: |
|||
| ? | 705-17-01880 | • PLATE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 07000-33032 | • O-RING | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01010-51025 | • BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 01643-51032 | • WASHER | 4 | Field_1: 25001- Field_2: |
