| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-06-Z2181 | HARNESS,ENGINE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 424-06-22120 | HARNESS,TRANSMISSION | 1 | Field_1: 25001- Field_2: |
|||
| ? | 419-15-Z8220 | PLUG | 1 | Field_1: 25001- Field_2: |
|||
| ? | 23206-52410 | THERMO-UNIT(TORQUE CONVERTER OIL TEMP)*1 | 1 | Field_1: 25001- Field_2: |
|||
| ? | 08052-12411 | CLIP | 1 | Field_1: 25001- Field_2: |
|||
| ? | 426-01-11310 | BRACKET | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 08053-01510 | CLIP | 2 | Field_1: 25001- Field_2: |
|||
| ? | 421-62-11940 | PLATE | 2 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 3 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01220 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 08052-12411 | CLIP | 3 | Field_1: 25143- Field_2: |
|||
| ? | 04434-51910 | CLIP | 4 | Field_1: 25001-25142 Field_2: |
|||
| ? | 42A-16-11210 | PLATE | 3 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 3 | Field_1: 25001- Field_2: |
|||
| ? | 04434-51710 | CLIP | 3 | Field_1: 25001- Field_2: |
|||
| ? | 426-06-11570 | BRACKET | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 426-06-11570 | BRACKET | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 1 | Field_1: 25001- Field_2: |
|||
| ? | 04434-51010 | CLIP | 3 | Field_1: 25001- Field_2: |
|||
| ? | 426-01-11310 | BRACKET | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 2 | Field_1: 25001- Field_2: |
|||
| ? | 08034-00519 | BAND | 1 | Field_1: 25001- Field_2: |
|||
| ? | 08052-12411 | CLIP | 3 | Field_1: 25001- Field_2: |
|||
| ? | 08034-20519 | BAND | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 04434-51010 | CLIP | 1 | Field_1: 25001- Field_2: |
|||
| ? | Field_1: Field_2: |
