| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-06-23231 | WIRING HARNESS,FRONT FRAME | 1 | Field_1: 25001- Field_2: |
|||
| ? | 08020-10000 | .DIODE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 424-06-12910 | GROMMET | 2 | Field_1: 25001- Field_2: |
|||
| ? | 08037-03614 | GROMMET | 2 | Field_1: 25001- Field_2: |
|||
| ? | 426-09-11210 | GROMMET | 2 | Field_1: 25001- Field_2: |
|||
| ? | 421-06-Z9210 | HORN.LOW | 1 | Field_1: 25001- Field_2: |
|||
| ? | 421-06-Z9220 | HORN.HIGH | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-00825 | BOLT | 4 | Field_1: 25001- Field_2: |
|||
| ? | 04434-52212 | CLIP | 2 | Field_1: 25001- Field_2: |
|||
| ? | 04434-51710 | CLIP | 2 | Field_1: 25001- Field_2: |
|||
| ? | 04434-51410 | CLIP | 1 | Field_1: 25001- Field_2: |
|||
| ? | 04434-51010 | CLIP | 6 | Field_1: 25001- Field_2: |
|||
| ? | 419-06-22570 | CONNECTOR | 2 | Field_1: 25001- Field_2: |
|||
| ? | 42A-16-11210 | PLATE | 1 | Field_1: 25001- Field_2: |
|||
| ? | 01435-01016 | BOLT | 15 | Field_1: 25001- Field_2: |
|||
| ? | 419-06-22570 | CONNECTOR | 1 | Field_1: 25001- Field_2: |
|||
| ? | 421-06-Z0130 | WIRING HARNESS | 2 | Field_1: 25001- Field_2: |
|||
| ? | 421-46-D7770 | PLATE | 1 | Field_1: 25210- Field_2: |
|||
| ? | 01643-31032 | WASHER | 1 | Field_1: 25210- Field_2: |
