| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6742-01-3270 | SCREW,M14X2.00X80 | 12 | Field_1: 21677326- Field_2: |
|||
| ? | 6742-01-5582 | GASKET,CYLINDER HEAD | 1 | Field_1: 21677326- Field_2: |
|||
| ? | 6743-11-1610 | SCREW,M14X2.00X160 | 14 | Field_1: 21677326- Field_2: |
|||
| ? | 6743-12-1110 | HEAD,CYLINDER | 1 | Field_1: 21677326- Field_2: |
|||
| ? | 6742-01-2990 | • COLLET,VALVE. | 24 | Field_1: 21677326- Field_2: |
|||
| ? | 1240952H2 | • VALVE,EXHAUST | 6 | Field_1: 21677326- Field_2: |
|||
| ? | 6742-01-0150 | • VALVE,INTAKE. | 6 | Field_1: 21677326- Field_2: |
|||
| ? | 6742-01-5224 | • SEAL,VALVE STEM | 6 | Field_1: 21677326- Field_2: |
|||
| ? | 6743-42-4110 | • SEAL,VALVE STEM | 6 | Field_1: 21677326- Field_2: |
|||
| ? | 6742-01-5530 | • HEAD,CYLINDER | 1 | Field_1: 21677326- Field_2: |
|||
| ? | 6742-01-1390 | • • PLUG,EXPANSION | 2 | Field_1: 21677326- Field_2: |
|||
| ? | 6742-01-2950 | • • INSERT,VALVE. | 6 | Field_1: 21677326- Field_2: |
|||
| ? | 6732-21-1820 | • • PLUG,EXPANSION | 5 | Field_1: 21677326- Field_2: |
|||
| ? | 1296803H1 | • • PLUG,EXPANSION | 1 | Field_1: 21677326- Field_2: |
|||
| ? | 6742-01-2990 | • • GUIDE,VALVE STEM | 12 | Field_1: 21677326- Field_2: |
|||
| ? | 1307586H1 | • • INSERT,VALVE. | 6 | Field_1: 21677326- Field_2: |
|||
| ? | 6741-11-1100 | • • HEAD,CYLINDER | 1 | Field_1: 21677326- Field_2: |
|||
| ? | 6743-41-4510 | RETAINER,VALVE SPRING | 12 | Field_1: 21677326- Field_2: |
|||
| ? | 6741-41-4410 | SPRING,VALVE. | 12 | Field_1: 21677326- Field_2: |
