| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20Y-977-1290 | JET HEATER UNIT | 1 | Field_1: 16001- Field_2: |
|||
| ? | 20Y-977-1330 | WATER PUMP | 1 | Field_1: 16001- Field_2: |
|||
| ? | 423-W93-Z513 | HARNESS | 1 | Field_1: 16001- Field_2: |
|||
| ? | 01435-00616 | BOLT | 2 | Field_1: 16001- Field_2: |
|||
| ? | 424-W93-Z860 | BRACKET | 1 | Field_1: 16001- Field_2: |
|||
| ? | 08037-02512 | GROMMET | 2 | Field_1: 16001- Field_2: |
|||
| ? | 01435-01220 | BOLT | 1 | Field_1: 16001- Field_2: |
|||
| ? | 07281-00259 | CLAMP | 4 | Field_1: 16001- Field_2: |
|||
| ? | 09483-10509 | HOSE | 1 | Field_1: 16001- Field_2: |
|||
| ? | 423-62-13770 | COVER | 1 | Field_1: 16001- Field_2: |
|||
| ? | 09483-10510 | HOSE | 1 | Field_1: 16001- Field_2: |
|||
| ? | 08034-00519 | BAND | 2 | Field_1: 16001- Field_2: |
|||
| ? | 07281-00137 | CLAMP | 1 | Field_1: 16001- Field_2: |
|||
| ? | 423-W93-Z170 | HOSE | 1 | Field_1: 16001- Field_2: |
|||
| ? | 08034-00519 | BAND | 4 | Field_1: 16001- Field_2: |
|||
| ? | 195-01-14540 | CUSHION | 4 | Field_1: 16001- Field_2: |
|||
| ? | 01435-01035 | BOLT | 4 | Field_1: 16001- Field_2: |
|||
| ? | 09484-00560 | CONNECTOR | 1 | Field_1: 16001- Field_2: |
|||
| ? | 423-W93-Z150 | REDUCER | 1 | Field_1: 16001- Field_2: |
|||
| ? | 20Y-041-1290 | REDUCER | 1 | Field_1: 16001- Field_2: |
|||
| ? | 424-W93-Z300 | CLAMP | 1 | Field_1: 16001- Field_2: |
|||
| ? | 424-W93-Z230 | TEE | 1 | Field_1: 16001- Field_2: |
|||
| ? | 424-W93-Z310 | CLAMP | 5 | Field_1: 16001- Field_2: |
|||
| ? | 424-W93-Z160 | CONNECTOR | 2 | Field_1: 16001- Field_2: |
|||
| ? | 424-W93-Z230 | TUBE | 1 | Field_1: 16001- Field_2: |
|||
| ? | 09483-10506 | HOSE | 1 | Field_1: 16001- Field_2: |
|||
| ? | 07281-00259 | CLAMP | 2 | Field_1: 16001- Field_2: |
|||
| ? | 418-07-15110 | EBLOW | 1 | Field_1: 16001- Field_2: |
|||
| ? | 419-ACZ-8130 | VALVE | 1 | Field_1: 16001- Field_2: |
