| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 06120-02016 | BEARING | 2 | Field_1: 16001- Field_2: |
|||
| ? | 06122-02004 | SEAL | 2 | Field_1: 16001- Field_2: |
|||
| ? | 421-43-18890 | ROD | 1 | Field_1: 16001- Field_2: |
|||
| ? | 04256-50616 | JOINT,ROD | 1 | Field_1: 16001- Field_2: |
|||
| ? | 01508-40603 | NUT | 1 | Field_1: 16001- Field_2: |
|||
| ? | 04256-40615 | JOINT,ROD | 1 | Field_1: 16001- Field_2: |
|||
| ? | 426-09-11130 | NUT | 1 | Field_1: 16001- Field_2: |
|||
| ? | 01643-30623 | WASHER | 4 | Field_1: 16001- Field_2: |
|||
| ? | 426-09-11130 | NUT | 2 | Field_1: 16001- Field_2: |
|||
| ? | 421-877-1491 | TRUNNION | 1 | Field_1: 16001- Field_2: |
|||
| ? | 01580-11210 | NUT | 2 | Field_1: 16001- Field_2: |
|||
| ? | 421-43-18561 | LEVER ASS'Y | 1 | Field_1: 16001- Field_2: |
|||
| ? | 421-43-18970 | BUSHING | 2 | Field_1: 16001- Field_2: |
|||
| ? | 426-09-11140 | NUT | 1 | Field_1: 16001- Field_2: |
|||
| ? | 06143-30823 | WASHER | 1 | Field_1: 16001- Field_2: |
|||
| ? | 421-43-18591 | PLATE | 4 | Field_1: 16001- Field_2: |
|||
| ? | 04025-10620 | PIN | 4 | Field_1: 16001- Field_2: |
|||
| ? | 01641-20608 | WASHER | 4 | Field_1: 16001- Field_2: |
|||
| ? | 04052-10633 | PIN | 4 | Field_1: 16001- Field_2: |
