| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. 80198 INDICATES D21A-7. THE OTHER MACHINES ARE AS FOLLOWS. | ||||||
| ? | D20A-7 = 80088 | ||||||
| ? | D20A-7B = 80059 | ||||||
| ? | D21A-7B = 80142 | ||||||
| ? | 104-54-39421 | CASE | 1 | SN: 78604-80198 |
|||
| ? | 01010-81025 | • BOLT | 2 | SN: 78604-@ |
|||
| ? | 01023-10406 | • SCREW | 2 | SN: 78604-@ |
|||
| ? | 01580-01008 | • NUT | 2 | SN: 78604-@ |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: 78604-@ |
|||
| ? | 09461-00020 | • LEVER ASS'Y | 1 | SN: 78604-@ |
|||
| ? | 103-54-34330 | • HINGE | 2 | SN: 78604-@ |
|||
| ? | 20B-54-12210 | • SPRING | 1 | SN: 78604-@ |
|||
| ? | 20N-60-11142 | GAUGE,OIL | 1 | SN: 78604-@ |
|||
| ? | 20N-60-11181 | • GASKET | 1 | SN: 78604-@ |
|||
| ? | 07002-02434 | O-RING | 1 | SN: 78604-@ |
|||
| ? | 07044-12412 | PLUG | 1 | SN: 78604-@ |
|||
| ? | 10E-03-11130 | CAP | 1 | SN: 78604-@ |
|||
| ? | 20G-54-19950 | CAP | 4 | SN: 78604-@ |
|||
| ? | 205-60-71220 | LOCK ASS'Y | 1 | SN: 78604-@ |
|||
| ? | 103-54-34450 | PLATE | 1 | SN: 78604-@ |
|||
| ? | 103-54-34460 | PLATE | 1 | SN: 78604-@ |
|||
| ? | 01010-81240 | BOLT | 4 | SN: 78604-@ |
|||
| ? | 01602-21236 | WASHER | 4 | SN: 78604-@ |
|||
| ? | 01643-31232 | WASHER | 4 | SN: 78604-@ |
|||
| ? | 113-60-43321 | CARTRIDGE | 1 | SN: 78604-@ |
|||
| ? | 113-60-43310 | BASE | 1 | SN: 78604-@ |
|||
| ? | 113-60-43330 | VALVE | 1 | SN: 78604-@ |
|||
| ? | 07000-03032 | O-RING | 1 | SN: 78604-@ |
|||
| ? | 01010-81025 | BOLT | 3 | SN: 78604-@ |
|||
| ? | 01602-21030 | WASHER | 3 | SN: 78604-@ |
|||
| ? | 104-60-33110 | NIPPLE | 1 | SN: 78604-@ |
|||
| ? | 103-60-23170 | NUT | 1 | SN: 78604-@ |
|||
| ? | 07002-02034 | O-RING | 1 | SN: 78604-@ |
|||
| ? | 103-60-33143 | HOSE | 1 | SN: 78604-@ |
|||
| ? | 07281-00359 | CLAMP | 2 | SN: 78604-@ |
|||
| ? | 103-60-23151 | ELBOW | 1 | SN: 78604-@ |
|||
| ? | 07002-03334 | O-RING | 1 | SN: 78604-@ |
|||
| ? | 113-60-23120 | NUT | 1 | SN: 78604-@ |
|||
| ? | 104-54-34340 | COVER | 1 | SN: 78604-@ |
|||
| ? | 01252-30825 | BOLT | 4 | SN: 78604-@ |
|||
| ? | 01643-30823 | WASHER | 4 | SN: 78604-@ |
|||
| ? | 114-54-43260 | PLUG | 4 | SN: 78604-@ |
