| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. 80198 INDICATES D21A-7. THE OTHER MACHINES ARE AS FOLLOWS. | ||||||
| ? | D20A-7 = 80088 | ||||||
| ? | D20A-7B = 80059 | ||||||
| ? | D21A-7B = 80142 | ||||||
| ? | 104-62-38170 | TUBE | 1 | SN: 78604-80198 |
|||
| ? | 104-62-38180 | TUBE | 1 | SN: 78604-80198 |
|||
| ? | 104-62-22350 | CLAMP | 2 | SN: 78604-80198 |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 78604-80198 |
|||
| ? | 01602-21030 | WASHER,SPRING | 2 | SN: 78604-80198 |
|||
| ? | 114-62-23150 | CLIP | 2 | SN: 78604-80198 |
|||
| ? | 01010-81035 | BOLT | 2 | SN: 78604-80198 |
|||
| ? | 01602-21030 | WASHER,SPRING | 2 | SN: 78604-80198 |
|||
| ? | 104-62-37211 | HOSE | 1 | SN: 78604-80198 |
|||
| ? | 113-06-23220 | COVER | 3 | SN: 78604-80198 |
|||
| ? | 08034-00414 | BAND | 2 | SN: 78604-80198 |
|||
| ? | 104-62-37250 | CLAMP | 3 | SN: 78604-80198 |
|||
| ? | 01010-81020 | BOLT | 3 | SN: 78604-80198 |
|||
| ? | 01602-21030 | WASHER,SPRING | 3 | SN: 78604-80198 |
|||
| ? | 104-62-37221 | HOSE | 2 | SN: 78604-80198 |
|||
| ? | 104-62-37450 | NIPPLE | 1 | SN: 78604-80198 |
|||
| ? | 113-06-23220 | COVER | 1 | SN: 78604-80198 |
|||
| ? | 104-62-37250 | CLAMP | 1 | SN: 78604-80198 |
|||
| ? | 01010-81020 | BOLT | 1 | SN: 78604-80198 |
|||
| ? | 01602-21030 | WASHER,SPRING | 1 | SN: 78604-80198 |
|||
| ? | 08034-00823 | BAND | 3 | SN: 78604-80198 |
|||
| ? | 104-62-33270 | CLIP | 1 | SN: 78604-80198 |
|||
| ? | 113-06-23220 | COVER | 2 | SN: 78604-80198 |
|||
| ? | 01010-80830 | BOLT | 1 | SN: 78604-80198 |
|||
| ? | 01602-20825 | WASHER,SPRING | 1 | SN: 78604-80198 |
