| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SERIAL NO. 80198 INDICATES D21A-7. THE OTHER MACHINES ARE AS FOLLOWS. | ||||||
| ? | D20A-7 = 80088 | ||||||
| ? | D20A-7B = 80059 | ||||||
| ? | D21A-7B = 80142 | ||||||
| ? | 20T-62-71150 | UNION | 2 | SN: 78604-80198 |
|||
| ? | 07002-11823 | O-RING | 2 | SN: 78604-80198 |
|||
| ? | 103-62-33112 | TUBE | 1 | SN: 78604-80198 |
|||
| ? | 103-62-33121 | TUBE | 1 | SN: 78604-80198 |
|||
| ? | 104-62-33250 | BRACKET | 1 | SN: 78604-80198 |
|||
| ? | 01010-51030 | BOLT | 2 | SN: 78604-80198 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 78604-80198 |
|||
| ? | 104-62-33111 | TUBE | 1 | SN: 78604-80198 |
|||
| ? | 104-62-33130 | TUBE,(FOR D20) | 1 | SN: 78604-80198 |
|||
| ? | 104-62-33130 | TUBE,(FOR F2-R2 TRANSMISSION) | 1 | SN: 78604-80198 |
|||
| ? | 104-62-33330 | TUBE,(FOR F3-R3 TRANSMISSION) | 1 | SN: 78604-80198 |
|||
| ? | 07283-21529 | CLIP | 2 | SN: 78604-80198 |
|||
| ? | 01598-00809 | NUT | 4 | SN: 78604-80198 |
|||
| ? | 01643-30823 | WASHER | 4 | SN: 78604-80198 |
|||
| ? | 104-62-33171 | CLAMP | 2 | SN: 78604-80198 |
|||
| ? | 01010-81020 | BOLT | 2 | SN: 78604-80198 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: 78604-80198 |
|||
| ? | 104-62-22350 | CLAMP | 2 | SN: 78604-80198 |
|||
| ? | 01010-81030 | BOLT | 2 | SN: 78604-80198 |
|||
| ? | 01602-21030 | WASHER,SPRING | 2 | SN: 78604-80198 |
