| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (706-7G-01040) | MOTOR ASS'Y | 1 | SN: 20002- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0. | ||||||
| ? | (706-7G-03040) | • MOTOR SUB ASS'Y | 1 | SN: 20002- |
|||
| ? | (★706-7G-41610) | • • SHAFT,DRIVE | 1 | SN: 20002- |
|||
| ? | (★706-75-42880) | • • BEARING | 1 | SN: 20002- |
|||
| ? | (★706-75-43810) | • • SPACER | 1 | SN: 20002- |
|||
| ? | (★706-7E-11260) | • • SPRING | 2 | SN: 20002- |
|||
| ? | (★706-7E-11270) | • • SEAT | 1 | SN: 20002- |
|||
| ? | (★706-76-40890) | • • BEARING | 1 | SN: 20002- |
|||
| ? | (★706-75-05040) | • • SPACER KIT | 1 | SN: 20002- |
|||
| ? | ☆ | • • • SPACER ? 3.1MM | 1 | SN: 20002- |
|||
| ? | ☆ | • • • SPACER ? 3.4MM | 1 | SN: 20002- |
|||
| ? | ☆ | • • • SPACER ? 3.7MM | 1 | SN: 20002- |
|||
| ? | 04064-04518 | • • RING,SNAP | 1 | SN: 20002- |
|||
| ? | 706-7E-11280 | • • SEAL,OIL | 1 | SN: 20002- |
|||
| ? | 706-75-43720 | • • SPACER | 1 | SN: 20002- |
|||
| ? | 04065-06220 | • • RING | 1 | SN: 20002- |
|||
| ? | (★706-7G-41210) | • • BLOCK,CYLINDER | 1 | SN: 20002- |
|||
| ? | (★706-7G-41710) | • • PLATE,VALVE | 1 | SN: 20002- |
|||
| ? | (★706-75-43750) | • • PIN,DOWEL | 1 | SN: 20002- |
|||
| ? | (★706-7G-41120) | • • SHAFT,CENTER | 1 | SN: 20002- |
|||
| ? | (★706-7G-41130) | • • RING,CENTER | 1 | SN: 20002- |
|||
| ? | (★706-7G-41140) | • • SPRING | 1 | SN: 20002- |
|||
| ? | (★706-7G-05010) | • • RETAINER KIT | 1 | SN: 20002- |
|||
| ? | ☆ | • • • RETAINER | 1 | SN: 20002- |
|||
| ? | ☆ | • • • SCREW | 7 | SN: 20002- |
|||
| ? | (★706-7G-41160) | • • PISTON SUB ASS'Y | 7 | SN: 20002- |
|||
| ? | (★706-7G-91340) | • • PLATE | 5 | SN: 20002- |
|||
| ? | (★706-7G-91350) | • • DISC | 4 | SN: 20002- |
|||
| ? | (★706-7G-91110) | • • PISTON,BRAKE | 1 | SN: 20002- |
|||
| ? | (★706-77-40370) | • • O-RING | 1 | SN: 20002- |
|||
| ? | (★708-8F-31610) | • • O-RING | 1 | SN: 20002- |
|||
| ? | (★706-7G-91360) | • • SPRING | 6 | SN: 20002- |
