| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-27-10200) | CONTROL VALVE ASS'Y | 1 | SN: 1002-1012 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6211 TO 6214. | ||||||
| ? | ☆ | • VALVE | 1 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE | 2 | SN: 1002-@ |
|||
| ? | 723-30-51130 | • ORIFICE | 2 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE | 1 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE | 1 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE | 1 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE | 1 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE SUB ASS'Y | 2 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE | 2 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE | 1 | SN: 1002-@ |
|||
| ? | 723-26-51150 | • PISTON | 4 | SN: 1002-@ |
|||
| ? | 723-26-14140 | • SPRING | 6 | SN: 1002-@ |
|||
| ? | 723-26-15230 | • PLUG | 12 | SN: 1002-@ |
|||
| ? | 07002-12434 | • O-RING | 12 | SN: 1002-@ |
|||
| ? | 07000-12010 | • O-RING | 7 | SN: 1002-@ |
|||
| ? | ☆ | • VALVE | 6 | SN: 1002-@ |
|||
| ? | 723-26-15220 | • PLUG | 6 | SN: 1002-@ |
|||
| ? | 723-26-14150 | • SPRING | 6 | SN: 1002-@ |
|||
| ? | 07002-11223 | • O-RING | 6 | SN: 1002-@ |
|||
| ? | 723-26-15170 | • PLUG | 1 | SN: 1002-@ |
|||
| ? | 723-26-15180 | • PLUG | 1 | SN: 1002-@ |
|||
| ? | 723-26-15190 | • PLUG | 1 | SN: 1002-@ |
|||
| ? | 708-8E-16160 | • PLUG | 1 | SN: 1002-@ |
|||
| ? | 706-73-71450 | • PLUG | 1 | SN: 1002-@ |
|||
| ? | 07002-11423 | • O-RING | 2 | SN: 1002-@ |
|||
| ? | 07002-11023 | • O-RING | 1 | SN: 1002-@ |
|||
| ? | 07000-11007 | • O-RING | 2 | SN: 1002-@ |
|||
| ? | 07001-01007 | • RING,BACK-UP | 2 | SN: 1002-@ |
|||
| ? | 07000-11009 | • O-RING | 1 | SN: 1002-@ |
|||
| ? | 07001-01009 | • RING,BACK-UP | 1 | SN: 1002-@ |
|||
| ? | 07002-01423 | • O-RING | 1 | SN: 1002-@ |
|||
| ? | 723-20-85100 | • PLUG ASS'Y | 1 | SN: 1002-@ |
|||
| ? | 723-20-60700 | • VALVE ASS'Y | 1 | SN: 1002-@ |
|||
| ? | 723-20-70100 | • VALVE ASS'Y | 1 | SN: 1002-@ |
|||
| ? | 723-20-80100 | • VALVE ASS'Y,SUCTION | 10 | SN: 1002-@ |
|||
| ? | 709-70-75100 | • VALVE ASS'Y,SUCTION AND SAFETY | 1 | SN: 1002-@ |
|||
| ? | 07043-70108 | • PLUG | 1 | SN: 1002-@ |
|||
| ? | 709-25-11390 | • O-RING | 1 | SN: 1002-@ |
|||
| ? | 07000-12012 | • O-RING | 1 | SN: 1002-@ |
|||
| ? | 07001-02012 | • RING,BACK-UP | 1 | SN: 1002-@ |
