| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | KWKKS-75-56003 | CONVEYOR ASS'Y,(7M) | 1 | SN: 1002- |
|||
| ? | KWKKS-75-57003 | CONVEYOR ASS'Y,(10M) | 1 | SN: 1002- |
|||
| ? | KWKKS-75-71372 | • MOTOR | 1 | SN: 1002- |
|||
| ? | KWKKS-75-53140 | • HOUSING | 1 | SN: 1002- |
|||
| ? | 07020-00000 | • FITTING | 1 | SN: 1002- |
|||
| ? | 01252-41235 | • BOLT | 2 | SN: 1002- |
|||
| ? | KWKKS-75-71380 | • BEARING | 1 | SN: 1002- |
|||
| ? | KWKKS-75-71390 | • SEAL | 1 | SN: 1002- |
|||
| ? | KWKKS-75-71280 | • HOUSING | 1 | SN: 1002- |
|||
| ? | 01252-40612 | • BOLT | 4 | SN: 1002- |
|||
| ? | 01010-51030 | • BOLT | 4 | SN: 1002- |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: 1002- |
|||
| ? | KWKKS-75-57161 | • COVER | 1 | SN: 1002- |
|||
| ? | 01010-51016 | • BOLT | 6 | SN: 1002- |
|||
| ? | 01643-31032 | • WASHER | 6 | SN: 1002- |
|||
| ? | 07113-00406 | • HOSE | 2 | SN: 1002- |
|||
| ? | 101-965-5120 | • NIPPLE | 2 | SN: 1002- |
|||
| ? | 07000-12018 | • O-RING | 2 | SN: 1002- |
|||
| ? | 07113-00306 | • HOSE | 1 | SN: 1002- |
|||
| ? | 209-62-54321 | • ELBOW | 1 | SN: 1002- |
|||
| ? | 07000-12011 | • O-RING | 1 | SN: 1002- |
|||
| ? | KWKKS-75-56160 | • TUBE,(7M) | 2 | SN: 1002- |
|||
| ? | KWKKS-75-57430 | • TUBE,(10M) | 2 | SN: 1002- |
|||
| ? | KWKKS-75-54170 | • TUBE,(7M) | 1 | SN: 1002- |
|||
| ? | KWKKS-75-55210 | • TUBE,(10M) | 1 | SN: 1002- |
|||
| ? | KWKKS-75-56170 | • TUBE,(7M) | 2 | SN: 1002- |
|||
| ? | KWKKS-75-57440 | • TUBE,(10M) | 2 | SN: 1002- |
|||
| ? | KWKKS-75-54190 | • TUBE,(7M) | 1 | SN: 1002- |
|||
| ? | KWKKS-75-55240 | • TUBE,(10M) | 1 | SN: 1002- |
|||
| ? | 07095-00317 | • CUSHION,(7M) | 5 | SN: 1002- |
|||
| ? | 07095-00317 | • CUSHION,(10M) | 9 | SN: 1002- |
|||
| ? | 07094-00315 | • CLAMP,(7M) | 5 | SN: 1002- |
|||
| ? | 07094-00315 | • CLAMP,(10M) | 9 | SN: 1002- |
|||
| ? | 01010-51230 | • BOLT,(7M) | 5 | SN: 1002- |
|||
| ? | 01010-51230 | • BOLT,(10M) | 9 | SN: 1002- |
|||
| ? | 01643-31232 | • WASHER,(7M) | 5 | SN: 1002- |
|||
| ? | 01643-31232 | • WASHER,(10M) | 9 | SN: 1002- |
|||
| ? | 07095-00421 | • CUSHION,(7M) | 10 | SN: 1002- |
|||
| ? | 07095-00421 | • CUSHION,(10M) | 18 | SN: 1002- |
|||
| ? | 07094-20417 | • CLAMP,(7M) | 5 | SN: 1002- |
|||
| ? | 07094-20417 | • CLAMP,(10M) | 9 | SN: 1002- |
|||
| ? | 01010-51240 | • BOLT,(7M) | 5 | SN: 1002- |
|||
| ? | 01010-51240 | • BOLT,(10M) | 9 | SN: 1002- |
|||
| ? | 01643-31232 | • WASHER,(7M) | 5 | SN: 1002- |
|||
| ? | 01643-31232 | • WASHER,(10M) | 9 | SN: 1002- |
|||
| ? | 07113-00455 | • HOSE | 2 | SN: 1002- |
|||
| ? | 07238-10315 | • CONNECTOR | 1 | SN: 1002- |
|||
| ? | 07113-00355 | • HOSE | 1 | SN: 1002- |
|||
| ? | 07238-10422 | • CONNECTOR | 2 | SN: 1002- |
|||
| ? | KWKKS-75-11790 | • COUPLER | 1 | SN: 1002- |
|||
| ? | KWKKS-75-11810 | • COUPLER | 1 | SN: 1002- |
|||
| ? | KWKKS-75-11870 | • COUPLER | 1 | SN: 1002- |
|||
| ? | 176-62-15490 | • NIPPLE | 1 | SN: 1002- |
|||
| ? | KWKKS-75-51430 | • COUPLER | 1 | SN: 1002- |
|||
| ? | KWKKS-75-51460 | • NIPPLE | 1 | SN: 1002- |
|||
| ? | KWKKS-75-11870 | • COUPLER | 1 | SN: 1002- |
