| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20Y-30-00022 | CARRIER ROLLER ASS'Y | 4 | SN: 1001- |
|||
| ? | 20Y-30-15221 | • ROLLER | 1 | SN: 1001- |
|||
| ? | 06002-32010 | • BEARING | 2 | SN: 1001- |
|||
| ? | 20Y-30-15131 | • SHAFT | 1 | SN: 1001- |
|||
| ? | 20Y-30-00070 | • FLOATING SEAL ASS'Y | 1 | SN: 1001- |
|||
| ? | 20Y-30-00080 | • • SEAL RING ASS'Y | 1 | SN: 1001- |
|||
| ? | ☆ | • • • RING | 2 | SN: 1001- |
|||
| ? | 20Y-30-00090 | • • O-RING ASS'Y | 1 | SN: 1001- |
|||
| ? | ☆ | • • • O-RING | 2 | SN: 1001- |
|||
| ? | 20Y-30-15121 | • RING | 1 | SN: 1001- |
|||
| ? | 141-30-35140 | • NUT | 1 | SN: 1001- |
|||
| ? | 141-30-35150 | • RING | 1 | SN: 1001- |
|||
| ? | 20Y-30-15140 | • COVER | 1 | SN: 1001- |
|||
| ? | 01010-51025 | • BOLT | 3 | SN: 1001- |
|||
| ? | 20Y-30-16330 | • PLUG | 1 | SN: 1001- |
|||
| ? | 07000-02075 | • O-RING | 1 | SN: 1001- |
|||
| ? | 01010-31675 | BOLT | 8 | SN: 1001- |
|||
| ? | 01643-31645 | WASHER | 8 | SN: 1001- |
